2. At-A-Glance Executive Brief

• Model: ABB 086329-004
• Brand: ABB
• Series / Platform: ABB ECS / Accuray
• Part Type: PWA / Circuit Board
• Catalog Description: PWA, ECS, END COL SNSR -104
• Core Function: Provides the electronic circuitry used in the ECS end-column sensor assembly.
• Key Specifications: 153 mm length × 10 mm height × 3 mm width; net weight approximately 0.26 kg.
• Related Identifier: ABB’s parts database lists 086329-104 separately as an ECS board with PROM upgrade kit, while 086329-004 is listed as the ECS end-column sensor PWA.
• Lifecycle: Legacy / discontinued in aftermarket records; suitable sourcing should therefore focus on exact part-number matching and spare availability.

3. Product Introduction

A failed sensor board inside an older control installation can turn a relatively small electronic fault into a much longer maintenance event when the original spare is no longer part of normal production inventory. ABB 086329-004 is identified as PWA, ECS, END COL SNSR -104, with ABB’s product record confirming the exact product identifier.

The board belongs to the ECS end-column sensor hardware group associated with ABB Accuray equipment. ABB’s parts listing also shows nearby ECS variants such as 086329-001, 086329-002, 086329-003, and 086329-004, so exact part-number verification matters before substitution.

From a procurement standpoint, the published dimensions are approximately 153 × 10 × 3 mm, with a net weight of 0.26 kg. The item is classified as a spare part, has an MOQ of one piece, and is listed as not made to order.

4. Core Technical Specifications

Parameter	Value
Manufacturer	ABB
Part Number	086329-004
ABB Type Designation	HKQCS PARTS ON LINE
Catalog Description	PWA, ECS, END COL SNSR -104
Long Description	PWA, ECS, END COLUMN SNSR
Product Name	PWA, ECS, END COL SNSR -104
Product Type	Spare Parts
Part Type	New
Functional Type	ECS End Column Sensor PWA
Product Length	153 mm
Product Height	10 mm
Product Width	3 mm
Net Weight	0.26 kg
Minimum Order Quantity	1 piece
Order Multiple	1 piece
Made to Order	No
Quote Only	No
Customs Tariff Number	85340019
WEEE Category	Product Not in WEEE Scope

ABB 086329-004

The above identification and dimensional data are published in ABB-related product records and supplier catalogs.

5. Application Scenarios & Pain Points

The key maintenance conclusion is simple: this board should be treated as an exact-replacement component rather than a generic control card.

1. Legacy ECS system maintenance

When an existing ABB ECS installation develops an end-column sensor problem, 086329-004 can be sourced as the matching PWA identified by its complete part number. This is particularly useful for plants maintaining older Accuray hardware.

2. Industrial control spare inventory

For equipment that has been operating for many years, keeping one or more verified spare boards can reduce the procurement delay associated with obsolete hardware. (This becomes more important when the installed system remains production-critical.)

3. Power and electrical installations

Within an ECS-based control architecture, the end-column sensor circuitry contributes to the associated sensing function. Replacement work should include inspection of the mating connectors and surrounding wiring rather than changing the board in isolation.

4. High-temperature plant environments

At 50°C+ ambient temperatures, maintenance personnel should inspect the complete sensor assembly for heat-related deterioration, contamination, connector degradation, and other environmental factors before returning the system to service.

5. Obsolescence planning

Third-party lifecycle records classify 086329-004 as discontinued, while ABB’s current product page still maintains the product identifier. For users operating installed legacy equipment, this combination makes advance spare planning worthwhile.

6. Common Error Codes & Diagnostic Symptoms

No dedicated numerical fault-code table for 086329-004 was found in the available product documentation. The following are therefore hardware-level diagnostic symptoms, rather than invented ABB error numbers.

• Symptom/Code: ECS end-column sensor feedback missing → Diagnosis: The sensing circuit may have an open connection, defective PWA, or failed associated component → Action: Check field wiring and connections, then replace the 086329-004 board if the fault is isolated to the PWA.
• Symptom/Code: Intermittent sensor indication → Diagnosis: An unstable connector, damaged PCB connection, contamination, or deteriorated electronic component can interrupt the sensor signal → Action: Inspect the board and mating interface; replace the PWA when the fault follows the board.
• Symptom/Code: Persistent ECS sensor alarm after wiring verification → Diagnosis: If the external sensor circuit and wiring have passed inspection, the end-column sensor PWA becomes a primary hardware suspect → Action: Install a verified compatible replacement and perform the applicable ECS functional test.

7. Cross-Reference & Lifecycle Migration

Related ABB Part Numbers

ABB’s OnCare parts database identifies several ECS sensor boards in the same part-number family:

Previous Revision / Replacement Information

Several aftermarket catalogs identify 086329-104 as the older product ID associated with 086329-004.

However, the two numbers should not automatically be treated as universal drop-in equivalents. The ABB parts listing categorizes 086329-104 as an ECS board with PROM upgrade kit, while 086329-004 is specifically listed as the ECS end-column sensor PWA.

Firmware / PROM

The 086329-103 and 086329-104 entries explicitly reference PROM upgrade kits. There is no equivalent public listing establishing that every 086329-004 installation requires firmware flashing. For a replacement project, compare the installed board identification, revision markings, PROM configuration, and host ECS hardware before commissioning.

Lifecycle Status

Legacy / Discontinued

Radwell identifies 086329-004 as discontinued by the manufacturer, although replacement and refurbished inventory remains available through the aftermarket.

For a plant still dependent on this ECS hardware, maintaining verified buffer stock is a sensible maintenance strategy rather than waiting for a failed board before beginning the sourcing process.
