ABB 1TGB302004R5003 | ABB Protection Module Compatible With Plant Control Racks

$1,741.00

ABB 1TGB302004R5003 serves as branch circuit overcurrent and short-circuit protection for control panel auxiliary loads. It fits standard panel mounting arrangements and matches original trip characteristics required for legacy automation cabinets.
Brand model：ABB
Product Name:1TGB302004R5003
Warranty: 1 year
Origin:Switzerland
HS code：85389000.00
Inventory: Spot/Futures
Goods condition: Brand new
Delivery time: 3-4days/1month

Request Quote
Brand: Model/SKU: ABB 1TGB302004R5003

Get a Quote / Inquiry

Request a Quote
Added View List
Email Inquiry
Phone/WhatsApp/Wechat:
+86 180 5988 4797
Email:
sales@powerdukedcs.com
WeChat QR Code WhatsApp

Description

2. At-A-Glance Executive Brief

  • Brand: ABB
  • Model: 1TGB302004R5003
  • Part Type: Low Voltage Circuit Breaker
  • Lifecycle status: Obsolete OEM production, available via surplus and refurbished stock
  • System compatibility: Industrial motor control and DCS auxiliary power circuits
  • Approximate unit weight: 0.45kg

3. Technical Introduction (Structure C)

Unplanned tripping and aged protection components create unplanned downtime within plant auxiliary power loops. Many sites struggle to source direct drop-in replacements once OEM series manufacturing ceases.

ABB 1TGB302004R5003 serves as branch circuit overcurrent and short-circuit protection for control panel auxiliary loads. It fits standard panel mounting arrangements and matches original trip characteristics required for legacy automation cabinets. The unit stabilizes power delivery to I/O racks, sensors and auxiliary control hardware by isolating fault currents before damage propagates to sensitive PLC hardware.

4. Core Technical Specifications

  • Model: 1TGB302004R5003
  • Manufacturer: ABB
  • Device Type: Low Voltage Moulded Case Circuit Breaker
  • Application: Industrial control panel circuit protection
  • Mounting: Standard DIN rail panel installation

    Please refer to the OEM datasheet for complete environmental tolerances.

    ABB 1TGB302004R5003

    ABB 1TGB302004R5003

5. Field Engineer’s Tech Notes

  1. Trip curve calibration cannot be modified on this fixed-spec unit. Confirm load current requirements before installation; mismatched trip profiles lead to nuisance tripping under normal operating conditions.
  2. Check terminal screw torque during commissioning. Loose terminals generate thermal buildup that accelerates contact degradation, especially in continuous 24/7 plant operation environments.

6. Adaptive QA & Testing Protocol

Each ABB 1TGB302004R5003 unit undergoes continuity testing across main contact terminals. Technicians verify mechanical switching operation and check for visible contact wear. Insulation resistance testing is completed to confirm internal dielectric integrity. Full test reports or recorded test footage can be shared upon formal request.

ABB 1TGB302004R5003

ABB 1TGB302004R5003

7. Buyer’s FAQ

Q: Can this unit directly replace older ABB circuit breaker variants installed in existing control cabinets?

A: Physical footprint and terminal layout match the original factory fit. Verify trip ratings against existing equipment before swap-out.

Q: What conditions are available for the ABB 1TGB302004R5003?

A: We supply new surplus NSFP and fully tested refurbished units. Stock condition is clearly noted on each quotation.

Q: How long is the warranty provided on spare part orders?

A: Standard warranty terms differ between new surplus and refurbished inventory, full details will be listed on your proforma invoice.

Q: What lead times apply for out-of-stock requests of this obsolete breaker?

A: Lead time depends on global surplus sourcing; confirmed availability and timeline will be advised within one working day of inquiry.
