ABB 560CMR01 1KGT036500R0001 | Industrial Automation Asset

Description

1. ABB 560CMR01 1KGT036500R0001 | Industrial Automation Asset

Unboxing & Physical Snapshot

• Brand & Model: ABB 560CMR01 1KGT036500R0001
• Product Family: ABB industrial control and communication hardware.
• Product Type: Rack-mounted control/communication module used within ABB automation system architectures.
• Primary Function: Provides system communication and control interface functions between automation components.
• Approximate Physical Dimensions: Approximately 250 × 160 × 40 mm (9.8 × 6.3 × 1.6 in), depending on installed rack configuration.
• Estimated Shipping Weight: Approximately 0.8–1.2 kg (1.8–2.6 lb) including ESD packaging.
• Mechanical Features:
  • PCB assembly
  • Rack insertion guide
  • Rear backplane connector
  • Front identification plate
  • Retaining hardware
• Cooling Method: Natural cabinet convection airflow.
• Front Interface Features:
  • Status indicators (configuration dependent)
  • Module identification label
  • Extraction handle
• What’s in the Box:
  • ABB 560CMR01 1KGT036500R0001 module
  • Anti-static ESD shielding bag
  • Protective packaging
  • Documentation when supplied

Product Introduction

The ABB 560CMR01 installs into the automation rack infrastructure where controlled communication between system components must remain stable. Its rear connector mates directly with the rack backplane, creating the electrical path required for system operation (which makes connector condition and mechanical alignment critical during replacement activities).

Handle this module as a controlled electronic asset. Inspect the edge contacts, front retaining mechanism, and PCB protection surfaces before installation. A module that has been stored correctly may still require verification of hardware revision, rack compatibility, and system configuration before returning equipment to service.

Core Technical Specifications

ABB 560CMR01 1KGT036500R0001

Global Compliance & Industry Certifications

Expected regulatory approvals and compliance considerations for the ABB 560CMR01 include:

• CE Mark — applicable when installed within a compliant ABB automation system meeting EMC requirements.
• UL/cUL Recognition — may apply depending on the complete control cabinet certification.
• RoHS Compliance — applicable to current manufacturing revisions.
• IEC industrial automation equipment standards — relevant when evaluated as part of a complete control system.
• ATEX/IECEx — requires confirmation of the complete hazardous-area installation, including enclosure, wiring, and associated certified equipment.
• Marine approvals (DNV GL, ABS, or LR) — only applicable when included within a certified marine automation package.

For industrial facilities handling combustible materials, approved hazardous-area installation methods are important because certified equipment combinations reduce the possibility of ignition sources within classified areas.

Verify specific lot certifications with OEM.

Long-Term Storage & Asset Preservation Guide

• Keep the ABB 560CMR01 inside the original anti-static (ESD) shielding bag during storage. The backplane connector contacts are sensitive to contamination and oxidation.
• Maintain storage humidity below 60% RH. Excess moisture can degrade connector surfaces and affect electrical contact performance after installation.
• Store vertically or on supported shelving to avoid mechanical stress on the PCB assembly and rack guides.
• Inspect the module every 12 months. Check the label condition, connector cleanliness, packaging integrity, and signs of corrosion.
• Record serial number, hardware revision, and storage inspection history for audit documentation.

ABB 560CMR01 1KGT036500R0001

Physical Installation Prerequisites

• Install the 560CMR01 only in the compatible ABB rack or chassis system.
• Confirm the rear backplane connector is clean and free of oxidation before insertion.
• Leave at least 50 mm above and below the rack assembly to support natural convection cooling.
• Verify cabinet grounding before connecting or energizing the module.
• Avoid installation in areas with conductive dust, excessive vibration, or corrosive chemical exposure.
• Ensure retaining screws or clips are secured to prevent movement during equipment operation.
• Follow ABB-approved procedures for module insertion and removal.

Buyer’s FAQ (Logistics & Compliance Focus)

Q: What HS Tariff Code is commonly used for the ABB 560CMR01 1KGT036500R0001?

A: Industrial automation modules are commonly evaluated under HS 8537 for electrical control equipment assemblies. Final classification depends on the importing country’s customs interpretation and the declared function of the module.

Q: Does Country of Origin (COO) affect ABB 560CMR01 purchasing records?

A: Yes. COO information supports customs clearance, supplier qualification, warranty tracking, and regulated facility audits. Keep the ABB nameplate, purchase records, and original packaging together.

Q: Should shipping insurance be included for this module?

A: Recommended. The unit contains precision electronic components and rack connectors that can suffer hidden damage from shock, vibration, or improper handling during international transport.

Q: Does the ABB 560CMR01 include the latest firmware pre-loaded?

A: Firmware availability depends on the specific ABB system platform and hardware revision. This type of rack module may require compatibility verification with the installed control software version before commissioning. Confirm revision details before deployment.
