ABB GFD233A103 3BHE022294R0103 | PEC Control Module

Description

• Model: GFD233A103
• ABB Product ID: 3BHE022294R0103
• Part Type: PEC80 LIN Module
• ABB Designation: GF D233 A: PEC80 LIN (NS=8)
• System Family: ABB AC 800PEC / power-electronics control systems
• Lifecycle: No longer for sale according to ABB product data; replacement status should be checked before procurement.

Technical Introduction

The ABB GFD233A103 3BHE022294R0103 is an ABB PEC80 LIN module associated with the AC 800PEC family of power-electronics control equipment.

ABB’s product record identifies the exact article as “GF D233 A: PEC80 LIN (NS=8)” and states that the product is no longer for sale. That makes accurate hardware identification important for legacy-system maintenance, particularly when a plant is maintaining an installed AC 800PEC or related power-control system instead of migrating immediately to a newer control platform.

Best Suited For

• ABB AC 800PEC legacy-system maintenance
• Replacement of an installed GFD233A103 module
• Critical spare inventory for power-electronics control equipment

Core Technical Specifications

ABB GFD233A103 3BHE022294R0103

*These fields come from ABB’s published product record and should be treated as commercial master-data information rather than a reliable indicator of the actual shipped module weight or country of manufacture for every physical unit.

ABB’s product record does not provide enough verified public information to safely state the module’s detailed electrical ratings, connector pinout, operating temperature, dimensions, or firmware requirements. Those values should be confirmed against the applicable OEM documentation and the installed unit.

Field Engineer’s Tech Notes

1. Verify the complete material number before treating this as a replacement.
The important identifier is 3BHE022294R0103, not simply “GFD233A.” ABB’s product record distinguishes this exact variant as GF D233 A: LIN (NS=8), and legacy PEC hardware can have closely related variants with different functions or configurations.

2. Preserve the existing controller configuration before removal.
On an obsolete AC 800PEC installation, replacing a hardware board without recording the existing configuration can turn a simple spare-part swap into a commissioning problem. Photograph board labels, connectors, jumpers or switches, firmware information, and cabinet wiring before removing the installed unit.

Adaptive QA & Testing Protocol

For a LIN control module, incoming inspection begins with verification of the complete GFD233A103 / 3BHE022294R0103 identification, PCB and enclosure condition, connector integrity, mounting points, and signs of corrosion, overheating, impact, or improper storage.

Functional testing should be performed using an appropriate ABB AC 800PEC-compatible test arrangement rather than applying power to the board without the associated system interface. The test scope should include power-up behavior, diagnostic status, relevant control/interface communications, and correct module recognition by the host control system. Where application equipment permits, communication and signal-path verification should be performed without exposing the production converter to uncontrolled operating conditions.

Because ABB lists this article as no longer for sale, a replacement unit should also be checked for hardware revision and configuration compatibility before installation.

Test reports, inspection photographs, and available test videos can be provided upon request.

ABB GFD233A103 3BHE022294R0103

Buyer’s FAQ

What is ABB GFD233A103 3BHE022294R0103?

ABB identifies 3BHE022294R0103 as GF D233 A: LIN (NS=8), a spare-part module associated with ABB’s /AC 800PEC control architecture.

Is still an active ABB product?

ABB’s current product record states “No longer for sale.” For an installed legacy system, replacement availability therefore depends on remaining inventory, exchange stock, or qualified aftermarket sources.

Can another GFD233A variant be used as a direct replacement?

Do not assume so. Confirm the full 3BHE022294R0103 material number, installed hardware revision, system architecture, and application configuration before substitution.

What condition and warranty can be supplied?

Availability may include New Surplus (NSFP), used/tested, or refurbished inventory depending on stock. Request the exact condition, inspection/test scope, photographs, warranty terms, and shipping lead time before placing the PO.
