Bently 1-536067-4 096 |Position Eurocard Board Connector Assembly

Description

• Brand: Bently / Bently Nevada application reference
• Full Model Number: 1-536067-4
• Lifecycle Status: Obsolete connector component
• Core Function: 96-position Eurocard board-to-board connector assembly
• Top 3 Technical Specs: 96 positions; 3 rows × 32 contacts; 2.54 mm pitch
• Stock & Condition: Physical stock verification required; New Surplus / Unused; Emergency dispatch subject to QA release

Module 3: Obsolescence & Supply Chain Deep Dive

Before approving this part number as a Bently Nevada electronic module, procurement should resolve an important identification issue. The exact 1-536067-4 part number is officially cataloged by TE Connectivity as a 096 EURO TYPE R PIN AP ASSY, not as a vibration-monitoring electronics module. TE’s specification identifies it as a 96-position, three-row, board-to-board plug with 2.54 mm pitch, through-hole press-fit PCB termination, and a 12.47 mm termination-post/tail length. TE currently marks the part as obsolete.

This matters from a TCO and maintenance perspective. If the plant BOM uses 1-536067-4 as a Bently spare, the correct purchasing action is to verify the actual assembly drawing and connector location before treating it as a complete monitoring module. A connector-level replacement can be inexpensive compared with replacing an entire legacy PCB or rack assembly, but the wrong contact geometry can create immediate mating or signal-integrity problems. One third-party Bently listing associates the number with a vibration-monitoring application, but its technical description conflicts with TE’s manufacturer data, so that classification should not be accepted without physical and drawing-level verification.

Module 4: Compatibility & Replacement Matrix

Estimated switch cost/time: Connector replacement itself can often be completed within 30–90 minutes once the correct part and mating assembly are available. PCB removal, connector replacement, solder/press-fit work, and electrical inspection can extend the maintenance window to 2–4 hours.

Field Traps — Watch Out

• Manufacturer identification conflict: TE Connectivity’s official record identifies 1-536067-4 as a 096 Euro Type R Pin AP Assembly. Treat descriptions calling it a complete Bently vibration-monitoring module as unverified until the original equipment drawing confirms that designation.
• 96-position does not mean universal interchangeability: The connector has 96 positions, 3 rows, and 2.54 mm pitch, but keying, mounting, contact loading, and board thickness still have to match.
• Obsolescence status: TE marks the exact part as obsolete, so stock condition and actual manufacturing provenance deserve additional scrutiny.
• Pin numbering risk: Never rely on a generic Eurocard pinout. Compare the actual connector orientation and PCB drawing before reconnecting field or board-level wiring.

Bently 1-536067-4 096

Module 5: Quality Assurance & Testing SOP

Because the verified manufacturer information identifies 1-536067-4 as a connector assembly, QA should focus on mechanical and electrical integrity rather than firmware or application testing.

• Part-number verification: Confirm 1-536067-4 and the manufacturer marking where available.
• OEM anti-counterfeit visual inspection: Compare housing geometry, contact construction, labeling, molding quality, and manufacturing details with the verified TE configuration.
• Physical condition inspection: Check the housing for cracks, deformation, contamination, corrosion, and broken retention features.
• Contact inspection: Examine all 96 contacts for bent, recessed, oxidized, contaminated, or damaged pins.
• Dimensional verification: Confirm 96 positions, 3 rows × 32 contacts, and 2.54 mm pitch.
• Termination inspection: Verify the specified through-hole press-fit termination arrangement and approximately 12.47 mm termination-post/tail length where applicable.
• PCB footprint check: Compare connector mounting and contact locations against the receiving PCB drawing before installation.
• Mating-cycle test: Mate and unmate the connector with the approved counterpart to verify smooth engagement, retention, and proper contact alignment.
• Continuity testing: Test all required contacts using a calibrated continuity tester after installation.
• Isolation testing: Check adjacent contact pairs for unintended shorts or insulation faults according to the applicable assembly specification.
• Signal-path testing: Where installed on a Bently system PCB, verify representative signal continuity through the connector to the receiving circuitry.
• Mechanical retention test: Verify the connector remains securely seated under normal handling and vibration conditions.
• Extended observation: Monitor the assembly during representative operation for intermittent connection or contact-resistance problems.
• Final QC release: Record part number, manufacturer identification, dimensional checks, contact inspection results, photographs, test date, and QC authorization.

TE’s official data also identifies the connector as a board-to-board plug, with phosphor-bronze pin contacts, a gray polyester-glass-filled housing, and a maximum contact-current rating of 3 A. Those characteristics provide useful receiving-inspection criteria when the original equipment drawing permits direct comparison.

Module 6: Procurement & Lifecycle FAQ

Q1. Is the Bently 1-536067-4 genuinely in stock, and what is the cutoff for emergency shipping?
Physical inventory should be verified against the exact 1-536067-4 marking before the PO is accepted. Because the part is officially marked obsolete by TE Connectivity, actual physical stock should take precedence over catalog availability.

Q2. How do you guarantee the condition and authenticity of a 1-536067-4?
Require exact part-number verification, manufacturer identification, visual inspection of the 96 contacts, dimensional verification, mating inspection, and continuity testing. For an obsolete connector, photographs of the actual part and traceability markings should remain with the procurement record.

Q3. Is 1-536067-4 actually a Bently Nevada vibration-monitoring module?
The exact part-number evidence does not support that classification. TE Connectivity identifies 1-536067-4 as a 096 EURO TYPE R PIN AP ASSY, a 96-position Eurocard connector assembly. A third-party Bently listing describes it differently, so the equipment drawing or original label should be checked before the part is marketed or purchased as a Bently electronics module.

Q4. Are firmware compatibility issues relevant to 1-536067-4?
No, not for the connector itself. Firmware becomes relevant only to the electronic PCB or monitoring system in which the connector is installed. The connector-level checks are mechanical fit, contact configuration, PCB footprint, continuity, and signal integrity.

Q5. What warranty and return terms should be written into the PO?
Specify exact-part-number conformity, physical condition, contact integrity, DOA coverage, return authorization, inspection period, and traceability requirements. For obsolete connector stock, require photographs of the actual part before shipment and clearly define the acceptance criteria for bent or oxidized contacts.
