1. ELAU ISH100/30025 | Precision Automation Servo Motor Unit

2. At-A-Glance Executive Brief

• Model: ELAU ISH100/30025/0/0/00/0/00/01/00
• Brand: ELAU (Schneider Electric Motion)
• Series: ISH100 Servo Motor Family
• Part Type: AC Synchronous Servo Motor
• Core Function: Converts electrical drive commands into precise rotary motion for industrial automation axes, including positioning, indexing, and coordinated machine movement.
• Primary Use: PacDrive automation systems, packaging machinery, robotics, and high-speed production equipment.
• Key Specifications:
  • Servo motor size: ISH100 frame
  • Rated speed: 3000 rpm
  • Permanent magnet synchronous motor design
  • Compatible with ELAU PacDrive servo amplifiers
  • Resolver/encoder feedback dependent on configuration
• Typical Deployment: Machine automation cabinets, servo axis assemblies, and precision motion platforms.

3. Product Introduction

The ELAU ISH100/30025 servo motor is installed as the mechanical motion element within PacDrive-based automation systems, connecting directly with servo drives that manage position, velocity, and torque control. The motor converts controlled electrical energy into accurate mechanical rotation for machine axes where repeatability and dynamic response are required.

In field deployments, engineers usually treat servo motors as matched motion components rather than interchangeable motors. Before replacement, confirm shaft dimensions, flange size, feedback type, brake option, connector arrangement, and motor identification data. A visually similar motor may still require different drive parameters (which can affect tuning, current limits, and machine performance).

4. Core Technical Specifications

Parameter	Value
Manufacturer	ELAU / Schneider Electric Motion
Model Number	ISH100/30025/0/0/00/0/00/01/00
Product Type	AC Permanent Magnet Servo Motor
Motor Series	ISH100
Rated Speed	3000 rpm
Frame Size	100 mm
Motor Technology	Synchronous servo motor
Application	Industrial motion control
Feedback System	Encoder/resolver dependent on option code
Drive Compatibility	ELAU PacDrive servo amplifiers
Cooling Method	Natural convection
Mounting Style	Flange-mounted servo motor
Shaft Design	Machine coupling shaft
Protection Rating	Typically IP65 motor enclosure
Operating Temperature	Industrial machine environment
Weight	Approx. 10–15 kg (configuration dependent)

ELAU ISH100/30025

5. Application Scenarios & Pain Points

A failed servo motor can stop an entire production line because mechanical positioning errors usually affect the complete machine sequence.

• Packaging machinery: Used for synchronized movements in filling, sealing, labeling, and indexing equipment where cycle timing may require millisecond-level coordination.
• Robotics and handling systems: Provides controlled axis movement for pick-and-place applications operating continuously in production environments.
• Food and pharmaceutical equipment: Applied in clean production machines where repeatable motion and controlled acceleration are required.
• Printing and converting machinery: Supports tension control and precise rotary positioning during high-speed material processing.
• Machine retrofit projects: Existing ELAU PacDrive installations often require matching servo motors because replacing the complete motion system can require extensive engineering changes.

6. Common Error Codes & Diagnostic Symptoms

Symptom/Code: Servo Drive Overcurrent Fault
→ Diagnosis: Possible motor winding damage, mechanical overload, incorrect drive parameters, or insulation degradation.
→ Action: Check motor resistance and mechanical load, then replace the ISH100 servo motor if internal failure is confirmed.

Symptom/Code: Encoder Feedback Error / Position Lost
→ Diagnosis: Feedback cable damage, connector failure, or internal encoder fault may prevent accurate position detection.
→ Action: Inspect feedback wiring and replace the motor assembly if the feedback device is defective.

Symptom/Code: Excessive Motor Temperature Alarm
→ Diagnosis: Overload operation, insufficient cooling, bearing wear, or winding problems may increase thermal load.
→ Action: Verify operating conditions and replace the motor if thermal damage is present.

7. Cross-Reference & Lifecycle Migration

• Compatible Family: ELAU ISH100 servo motor series used with PacDrive motion systems.
• Replacement Considerations:
  • Match motor option code.
  • Verify feedback configuration.
  • Confirm brake availability.
  • Check shaft and flange specifications.
  • Validate servo drive parameter compatibility.
• Firmware Requirements:
  Servo motors do not typically contain application firmware. However, servo drive parameters, motor identification data, and machine tuning values may require restoration.
• Lifecycle Status: Legacy / Supported Through Installed Base
  • Widely found in existing ELAU PacDrive systems.
  • Maintain tested spare motors for machines where downtime has significant production impact.
• Migration Strategy:
  Modern Schneider Electric PacDrive platforms may support migration paths, but mechanical fit and drive compatibility must be verified before substitution.

8. Field Engineer’s Tech Notes (Anti-Pitfall Guide)

1. Do not replace the motor without recording drive parameters first.
   A new motor may physically fit but require different identification data and tuning values. Save the original servo amplifier configuration before removal.
2. Protect the feedback connector during handling.
   Encoder contacts are sensitive to contamination and mechanical impact. Avoid pulling cables by the connector body (the retaining hardware is designed for controlled removal).

9. Strict QA & Testing SOP

Step 1 — Incoming Inspection

• Verify ELAU ISH100/30025 complete ordering code.
• Record serial number and nameplate data.
• Inspect shaft, flange, connectors, and housing.
• Check for corrosion, impact marks, or oil contamination.

Step 2 — Mechanical Inspection

• Rotate shaft manually.
• Check bearing noise and mechanical resistance.
• Verify mounting dimensions.

Step 3 — Electrical Testing

• Measure winding resistance.
• Perform insulation resistance testing.
• Verify feedback circuit continuity.

Step 4 — Servo Drive Test

• Connect to compatible PacDrive servo amplifier.
• Verify motor identification.
• Check rotation direction and feedback response.
• Perform controlled motion test.

Step 5 — Packaging Control

• Secure shaft protection.
• Protect feedback connectors.
• Use shock-resistant packaging for international shipment.

Test videos are available for verified inspection records.

10. Buyer’s FAQ (Dynamic Q&A)

Q: Can the ELAU ISH100/30025 be replaced while the machine is running?

A: No. Servo motors are mechanical motion components connected to active drive systems. Power isolation and mechanical safety procedures are required before replacement.

Q: How can I verify this is an original ELAU ISH100/30025 motor?

A: Check the nameplate, complete ordering code, serial number, connector condition, shaft condition, and supplier inspection documentation.

Q: Does this servo motor require firmware installation?

A: The motor itself does not normally receive application firmware. The associated PacDrive servo drive may require parameter loading and motor identification configuration after replacement.

Q: What warranty information should be requested before purchasing?

A: Confirm whether the supplier provides functional testing, mechanical inspection results, replacement coverage, and protection against shipping damage. For servo motors, documented testing is important before installation.
