- AMAT 0090-00224 | Industrial I/O Expansion Assembly
Unboxing & Physical Snapshot
- Model & Brand: AMAT 0090-00224 (Applied Materials)
- Product Type: Applied Materials Centura Mainframe I/O Expansion Board used for semiconductor processing equipment control expansion. The 0090-00224 part number is listed as a Centura I/O Expansion Board / PCB assembly.
- Approximate Physical Dimensions (W × H × D):
- Approximately 160 × 100 × 30 mm
- Exact dimensions depend on installed bracket and chassis configuration.
- Estimated Shipping Weight:
- PCB assembly weight: approximately 0.3–0.6 kg
- Typical packaged shipping weight: 0.8–1.2 kg
- What’s in the Box:
- AMAT 0090-00224 I/O Expansion Board
- PCB assembly with edge connector/interface points
- Identification label
- Anti-static (ESD) shielding bag
- Protective foam packaging
- Documentation when supplied
Product Introduction
The AMAT 0090-00224 mounts inside Applied Materials Centura semiconductor equipment electronics sections, expanding the available I/O capability between the equipment controller and process subsystems. It acts as an interface layer for machine control signals, supporting communication between hardware assemblies such as sensors, interlocks, and process-control components (—which is critical for maintaining repeatable wafer processing sequences).
This board should be managed as a controlled semiconductor manufacturing spare. It is not interchangeable based only on physical fit. Verify the complete part number, revision level, equipment platform, and installed software configuration before replacement. Inspect the edge connector fingers, mounting holes, and PCB surface condition carefully. Semiconductor tools often run continuously for extended periods, so undocumented hardware changes can create difficult-to-trace production issues.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Applied Materials (AMAT) |
| Part Number | 0090-00224 |
| Equipment Family | Centura Semiconductor Processing System |
| Module Type | I/O Expansion Board |
| Function | Equipment control signal expansion |
| Application | Wafer fabrication equipment automation |
| PCB Type | Industrial control circuit board assembly |
| Input/Output Capability | Configuration dependent |
| Processor | System-dependent control electronics |
| Memory | Configuration-dependent |
| Communication Interface | Equipment backplane/interface bus |
| Power Supply | Machine chassis supplied power |
| Power Consumption | Low-power electronic assembly |
| Heat Dissipation | Passive PCB convection cooling |
| Mounting Method | Internal equipment chassis installation |
| Operating Environment | Semiconductor cleanroom equipment cabinet |
| Storage Requirement | Dry ESD-controlled environment |
AMAT 0090-00224
? Global Compliance & Industry Certifications
Expected regulatory considerations for the AMAT 0090-00224 include:
- CE Mark: Applicable when installed within a compliant Applied Materials semiconductor tool meeting EMC requirements.
- UL/cUL Listed: May apply at the complete equipment certification level.
- ATEX / IECEx: Generally not a standalone hazardous-area certified component. Hazardous-area suitability depends on the complete equipment installation.
- Marine Approvals (DNV GL): Normally not applicable unless installed within a specially certified marine manufacturing environment.
For semiconductor fabrication equipment, compliance is usually maintained through the complete tool certification package. Individual board substitutions should maintain equipment configuration records, revision history, and service documentation.
Verify specific lot certifications with OEM.
? Long-Term Storage & Asset Preservation Guide
Keep the AMAT 0090-00224 inside the original anti-static (ESD) shielding bag. Do not expose connector contacts to bare hands or uncontrolled environments.
Maintain warehouse humidity below 60% RH. Excess moisture can oxidize edge connectors and reduce contact reliability after installation.
Inspect stored boards every 12–24 months. Check the PCB coating, connector fingers, mounting points, and identification label. Confirm the board revision before returning it to production inventory.
Physical Installation Prerequisites
- Install the 0090-00224 only in the approved Applied Materials Centura equipment configuration.
- Verify board revision and equipment compatibility before insertion.
- Inspect chassis connectors for contamination or mechanical damage.
- Confirm grounding straps and chassis bonding points are secure.
- Maintain cleanroom handling procedures during installation.
- Leave approximately 50 mm clearance around ventilation paths where required for cabinet cooling.
- Use proper ESD protection during handling.
- Perform equipment diagnostics and I/O verification after replacement.
Buyer’s FAQ (Logistics & Compliance Focus)
Q: What HS Tariff Code is commonly used for the AMAT 0090-00224?
A: Semiconductor equipment control boards are commonly reviewed under HS 8538 or related electrical control component classifications. The final tariff classification depends on the importing country’s customs rules and declared function.
Q: Does Country of Origin (COO) affect this AMAT spare shipment?
A: Yes. COO documentation supports customs clearance, import compliance, and semiconductor asset traceability. Ensure the COO on commercial documents matches available product records.
Q: Is shipping insurance recommended for the 0090-00224?
A: Recommended. The board contains sensitive electronic circuits and precision connector interfaces. Transit shock, humidity, or ESD exposure can create failures that may only appear during equipment startup.
Q: Does the AMAT 0090-00224 include the latest firmware pre-loaded?
A: This board does not typically function as a standalone software controller. Any firmware or configuration dependency is equipment-specific. Verify compatibility with the installed Centura system configuration before commissioning.
