1. AMAT 1080-01772 | Original Applied Materials Spare Part

2. Unboxing & Physical Snapshot

• Brand & Model: Applied Materials (AMAT) 1080-01772
• Associated Hardware: Copley Controls 800-1814 series servo drive assembly. The part number is referenced in industrial spare-part listings as an Applied Materials configuration using a Copley motion drive.
• Product Type: AC servo motor controller / motion amplifier assembly.
• Application Area: Semiconductor manufacturing equipment motion systems, including precision wafer handling and mechanical positioning assemblies.
• Primary Function: Provides controlled servo power output for precision actuator movement inside Applied Materials process equipment.
• Approximate Physical Dimensions (W × H × D): Estimated 140 × 230 × 70 mm.
• Estimated Shipping Weight: Approximately 2–3 kg including industrial protective packaging.
• Mechanical Features:
  • Metal drive enclosure
  • Front communication interface
  • Power and motor output terminals
  • Control signal connector
  • Status indicator LEDs
  • Mounting flange/bracket points
• Mounting Style: Cabinet or equipment frame mounting.
• Cooling Method: Passive heatsink cooling with cabinet airflow assistance.
• Handling Requirements:
  • Use ESD protection.
  • Protect terminal pins and connectors.
  • Avoid impact to the aluminum housing.
• What’s in the Box:
  • AMAT 1080-01772 servo drive assembly
  • Protective ESD packaging
  • Foam shock protection
  • Inspection documentation when supplied

3. Product Introduction

Motion accuracy inside semiconductor equipment depends on controlled electrical conversion between the machine controller and the mechanical actuator. The AMAT 1080-01772 servo drive assembly provides the power electronics required for precision positioning tasks within compatible Applied Materials platforms (which is critical for wafer transfer mechanisms where repeatability affects equipment availability).

This component should be managed as a precision electronic asset. Inspect the enclosure, connector housings, terminal blocks, and heatsink surfaces before installation. Check the date code. Stored servo drives can develop capacitor aging, contact oxidation, or insulation degradation even when the exterior appears acceptable.

4. Core Technical Specifications

5. Global Compliance & Industry Certifications

Expected compliance considerations for the AMAT 1080-01772 include:

• CE Mark — commonly associated with servo drive EMC and low-voltage compliance requirements.
• UL/cUL Recognition — may apply to the servo drive assembly depending on the exact Copley configuration.
• SEMI Standards Consideration — semiconductor equipment installations commonly follow SEMI safety and equipment integration practices.
• ATEX/IECEx Considerations — required only for installations inside classified hazardous environments.
• Marine Approvals (DNV GL) — generally not applicable for semiconductor motion-control hardware.

Certification matters because servo drives control stored electrical energy and moving mechanical assemblies. Incorrect substitution can create safety risks during machine operation.

Verify specific lot certifications with OEM.

6. Long-Term Storage & Asset Preservation Guide

• Keep the AMAT 1080-01772 inside an ESD shielding bag until installation. Protect the control PCB, connectors, and feedback interfaces from static discharge.
• Maintain storage humidity below 60% RH. Moisture can accelerate corrosion on terminal contacts and internal electronic components.
• For extended storage periods, inspect electrolytic capacitor condition before commissioning. Capacitor reforming procedures may be required for older unused drives.
• Store the drive away from vibration, dust, chemical vapors, and temperature extremes. The heatsink and connector surfaces require clean storage conditions.
• Record serial number, firmware revision, hardware revision, and storage duration in the spare asset database.

7. Physical Installation Prerequisites

• Install only within the approved Applied Materials equipment configuration.
• Confirm motor compatibility, feedback wiring, and controller communication settings before replacement.
• Mount the drive on a rigid metal surface to support heatsink heat transfer.
• Leave at least 50 mm clearance around ventilation areas for proper airflow.
• Connect protective earth grounding before applying power.
• Verify input voltage and motor wiring before energization.
• Keep encoder and control wiring separated from high-current motor cables.
• Tighten terminal connections according to manufacturer specifications.

8. Buyer’s FAQ (Logistics & Compliance Focus)

Q: What HS Tariff Code is commonly used for AMAT 1080-01772?

A: Servo drive assemblies are commonly reviewed under HS 8504 classifications for electrical power conversion equipment or related control equipment categories. Final classification depends on the declared function and importing-country customs interpretation.

Q: Why does Country of Origin (COO) matter for this AMAT spare?

A: COO affects customs clearance, duty calculation, export documentation, and semiconductor equipment traceability. The COO should match the commercial invoice, packing list, and asset records.

Q: Should shipping insurance be purchased for the 1080-01772?

A: Recommended. Servo drives contain power electronics, capacitors, and precision connectors that can be damaged by impact, moisture, or improper handling during transportation.

Q: Does AMAT 1080-01772 include the latest firmware pre-loaded?

A: The servo drive normally contains factory-installed firmware according to its hardware revision. Confirm firmware compatibility with the existing Applied Materials motion-control configuration before installation.
