Emerson VE4003S2B4 | Traceable DCS Analog I/O Hardware

2. Unboxing & Physical Snapshot

Brand & Model: Emerson VE4003S2B4
Product Category: DeltaV M-Series Analog Input 16-Pin Mass Termination Block
Application: Designed for 8-channel 4–20 mA HART Analog Input Cards within the Emerson DeltaV M-Series Traditional I/O platform. It provides a 16-pin mass termination interface for efficient field wiring and cabinet organization.
Approximate Physical Dimensions: Approximately 5.1 × 4.0 × 2.0 in (130 × 102 × 51 mm), depending on carrier installation.
Estimated Shipping Weight: Approximately 0.46 lb (0.21 kg) including protective packaging.
What’s in the Box:
- Emerson VE4003S2B4 terminal block
- Factory-installed terminal hardware
- Product identification label
- Anti-static (ESD) protective packaging
- Installation documentation when supplied with OEM packaging

3. Product Introduction

Within a DeltaV control cabinet, field wiring terminates long before signals reach the controller processor. The Emerson VE4003S2B4 serves as the physical termination interface between plant instrumentation and the associated 8-channel Analog Input HART I/O card. Proper terminal selection is important because wiring layout, maintenance access, and signal integrity depend on the termination hardware (particularly during plant turnarounds when replacement time is limited).

Although electrically passive, this termination block plays a significant role in long-term system reliability. The connector interface, screw terminals, and molded housing should be inspected for cracks, corrosion, or loose hardware before installation. Even slight deformation of the terminal assembly can introduce intermittent field signal problems that resemble transmitter faults rather than cabinet issues.

4. Core Technical Specifications

Parameter	Value
Manufacturer	Emerson
Model Number	VE4003S2B4
Alternate Part Number	KJ3222X1-BA1
Product Type	Analog Input Mass Termination Block
Product Family	DeltaV M-Series Traditional I/O
Supported I/O Card	8-Channel Analog Input, 4–20 mA, HART
Termination Style	16-Pin Mass Termination
Signal Type	Analog Input
HART Support	Yes
Channel Capacity	8 Channels
Mounting Method	DeltaV I/O Carrier
System Compatibility	DeltaV M-Series (v10.3.1 and later for VE4003S2B4)
Power Consumption	Passive termination hardware
Heat Dissipation	Negligible
Operating Environment	Industrial control cabinet
Weight	Approximately 0.21 kg (0.46 lb)

Emerson VE4003S2B4

5. Global Compliance & Industry Certifications

Industrial hardware in this product class is commonly supplied with approvals such as:

CE Mark for EMC and Low Voltage Directive compliance where applicable.
UL/cUL Recognized components for installation within certified industrial control panels.
ATEX/IECEx compatibility when used with approved intrinsic safety barriers and certified DeltaV system architecture.
Marine approvals (DNV or equivalent) when incorporated into qualified offshore automation systems.

For hazardous-area applications, certification applies to the entire signal loop, not simply the terminal block. Intrinsic safety barriers, field devices, wiring practices, and I/O assemblies must all match the approved system design.

Verify specific lot certifications with OEM.
