1. Rexroth FCS01.1E-W0011-A-04-NNBV | 400V Drive

Unboxing & Physical Snapshot

• Model & Brand: Bosch Rexroth Indramat FCS01.1E-W0011-A-04-NNBV (Material Number R911311065). This unit is an FCS series frequency converter used for industrial motor control and motion-related applications.
• Product Type: AC Frequency Converter / Variable Speed Drive.
• Rated Current: Approximately 11 A maximum output current.
• Physical Dimensions (Approximate W × H × D): 73 × 226 × 153 mm (2.87 × 8.90 × 6.02 in.); approximately 260 mm height when rear mounting brackets are installed.
• Estimated Shipping Weight: Approximately 1.8 kg (4.0 lb) including industrial protective packaging.
• What’s in the Box:
  • Bosch Rexroth Indramat FCS01.1E-W0011-A-04-NNBV frequency converter
  • Front display interface (configuration dependent)
  • Terminal connection hardware
  • Rear mounting brackets
  • Protective packaging
  • ESD protection materials
  • Product identification label

Product Introduction

The Bosch Rexroth FCS01.1E-W0011-A-04-NNBV installs inside a protected electrical cabinet where the integrated blower and heatsink assembly can remove power-stage heat. Cabinet layout matters. Keep the ventilation channels open, inspect the mounting brackets, and confirm the rear cooling path is not blocked (which is critical for continuous-duty motor applications).

This frequency converter provides controlled AC motor operation with a maximum current rating of approximately 11 A and supports overload capability for dynamic industrial loads. The unit includes a four-line display, status LEDs, and supports external braking resistor connection for applications requiring additional energy handling during deceleration. Verify motor parameters, firmware revision, and stored configuration before replacing an installed drive.

Core Technical Specifications

Rexroth FCS01.1E-W0011-A-04-NNBV

Global Compliance & Industry Certifications

Expected compliance considerations for the Bosch Rexroth FCS01.1E-W0011-A-04-NNBV include:

• CE Mark — applicable for compliant industrial installations following EMC and machinery requirements.
• UL/cUL Recognition — may apply depending on the complete drive system configuration and installation conditions.
• RoHS Compliance — verify based on production revision and available documentation.
• IEC/EN 61800 Drive Standards — relevant for adjustable speed electrical power drive systems.
• ATEX/IECEx — not a standalone hazardous-area certified device; requires approved enclosure and system certification if used in classified locations.
• Marine approvals (DNV GL) — not typically applicable unless supplied as part of a certified marine automation package.

CE and EMC compliance are important for frequency converters because switching power electronics can generate conducted and radiated interference that affects nearby instrumentation and communication equipment.

Verify specific lot certifications with OEM.

Long-Term Storage & Asset Preservation Guide

Keep the .1E- sealed in its original packaging during storage. Protect the terminal blocks, display interface, and ventilation openings from dust contamination.

Maintain warehouse humidity below 60% RH. Long storage periods can affect electrolytic capacitors, connector surfaces, and insulation materials inside the power section.

Before energizing a stored unit:

• Check the manufacturing date code.
• Inspect the cooling fan operation.
• Verify connector condition.
• Review capacitor condition and perform controlled power-up procedures if required.
• Confirm parameter compatibility with the installed motor system.

Do not stack heavy items on the drive housing. The plastic display section and mounting brackets can be damaged by uneven mechanical loading.

Physical Installation Prerequisites

• Install inside a clean electrical cabinet with IP-rated protection.
• Mount vertically using the supplied rear mounting brackets.
• Ensure adequate airflow around the cooling openings.
• Leave approximately 100 mm clearance above and below the drive for ventilation.
• Side-by-side installation is possible where cabinet airflow design permits.
• Connect protective earth before applying power.
• Use correctly rated motor and supply cables.
• Separate encoder/signal wiring from high-current conductors.
• Install external braking resistor components according to application requirements.
• Verify cabinet temperature under operating load.

Buyer’s FAQ (Logistics & Compliance Focus)

Q: What HS Tariff Code is commonly used for the Rexroth .1E-?

A: Frequency converters are commonly classified under HS 8504.40 for static converters. Final classification depends on the importing country’s customs interpretation and the declared equipment function.

Q: Does Country of Origin (COO) affect importing this Rexroth drive?

A: Yes. COO affects customs clearance, duty treatment, warranty tracking, and industrial asset records. Ensure the COO on the commercial invoice, packing list, and product identification documents is consistent.

Q: Should shipping insurance be arranged for this frequency converter?

A: Recommended. The unit contains power semiconductors, capacitors, cooling components, and control electronics. Shock or moisture exposure during transportation may cause failures that appear only after commissioning.

Q: Does the .1E- include the latest firmware pre-loaded?

A: Firmware and parameter configuration depend on the specific drive revision and application setup. The replacement unit should be checked against the existing machine configuration before installation.
