- GE VMIVME-5565 | Traceable OEM Network Memory Module
Unboxing & Physical Snapshot
- Model & Brand: GE Fanuc / GE Intelligent Platforms VMIVME-5565
- Product Type: 6U VMEbus Reflective Memory Node Card for real-time fiber-optic data sharing networks.
- Approximate Physical Dimensions (W × H × D): Approximately 160 × 233 × 20 mm (6U VME Eurocard format)
- Estimated Shipping Weight: Approximately 1.0-1.5 kg (2.2-3.3 lb) including ESD packaging and protective inserts
- What’s in the Box:
- GE VMIVME-5565 VME reflective memory board
- Front panel assembly with ejector handles
- Fiber-optic transceiver interface
- Original anti-static ESD shielding bag (when supplied sealed)
- Protective foam/card carrier
- Hardware documentation when available
Product Introduction
The VMIVME-5565 is installed directly into the VME chassis ecosystem, where the 6U Eurocard slides into the backplane and becomes a node on a deterministic fiber-optic reflective memory network. The board is not a standalone controller; it depends on proper VME power rails, connector alignment, cooling airflow, and network topology. (Backplane condition is often the hidden failure point in aging VME installations.)
Designed for real-time data distribution, this GE reflective memory module allows multiple computers, controllers, and embedded systems to maintain synchronized shared memory copies through fiber-optic communication. The module supports network connections using multimode fiber up to approximately 300 meters and single-mode fiber up to approximately 10 kilometers, depending on optical configuration.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Model | VMIVME-5565 |
| Product Type | VMEbus Reflective Memory Node Card |
| Form Factor | 6U VME Eurocard |
| Bus Interface | VMEbus |
| Reflective Memory Size | 64 MB or 128 MB SDRAM (variant dependent) |
| Fiber Network Speed | 2.125 Gbaud serial fiber link |
| Non-Redundant Transfer Rate | Approximately 43 MB/s to 170 MB/s |
| Redundant Transfer Rate | Approximately 20 MB/s to 87 MB/s |
| Maximum Network Nodes | Up to 256 nodes |
| Fiber Type Support | Multimode and single-mode fiber options |
| Multimode Distance | Up to approximately 300 m |
| Single-Mode Distance | Up to approximately 10 km |
| VME Transfer Rate | Approximately 40 MB/s |
| Operating Temperature | 0°C to +65°C with forced-air cooling |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 20% to 80%, non-condensing |
| Power Requirement | +5 VDC and +3.3 VDC rails; configuration dependent |
| Maximum Heat Output | Approximately 10-15 W depending on memory and interface activity |
GE VMIVME-5565
? Global Compliance & Industry Certifications
Expected regulatory considerations for GE VMIVME-5565 industrial communication hardware include:
- CE Mark: Applicable for electromagnetic compatibility requirements on supported configurations.
- UL/cUL Recognition: May apply to installed system assemblies or certified equipment platforms.
- RoHS Compliance: Depends on production revision and manufacturing date.
- IEC industrial equipment compliance considerations: Applicable through the final installed system design.
- ATEX/IECEx: Not normally a standalone board certification; applicability depends on installation inside an approved hazardous-area enclosure.
- Marine approvals (DNV GL): Possible only for specific certified system packages.
For hazardous-area installations, certification applies to the complete approved assembly, not simply the replacement circuit board. A mismatched communication card can affect the certified equipment configuration.
Verify specific lot certifications with OEM.
? Long-Term Storage & Asset Preservation Guide
Keep the inside its original anti-static shielding bag whenever it is stored as a spare. The exposed VME edge connector and fiber interface are sensitive to contamination (especially in warehouses with airborne dust or chemical exposure).
Maintain storage humidity below 60% relative humidity and avoid repeated temperature cycling. Moisture condensation can affect optical components, connector plating, and PCB insulation properties over long periods.
Inspect the board every 12-24 months. Check the VME connector fingers, fiber-optic transmit/receive ports, ejector handles, and PCB surface condition. Do not use abrasive methods on connector contacts; the plating thickness is limited and mechanical damage can create intermittent faults.
Physical Installation Prerequisites
- Install the only in a compatible 6U VME chassis with the correct backplane architecture.
- Leave at least 50 mm clearance above and below airflow paths where cabinet design permits.
- Confirm forced-air cooling operation before applying power.
- Verify the VME backplane connectors are clean, aligned, and free from damaged contacts.
- Connect the chassis protective earth before insertion.
- Use the front-panel ejector handles for installation and removal; do not force the PCB edge connector manually.
- Confirm fiber-optic cable type matches the installed transceiver option before commissioning.
GE VMIVME-5565
Buyer’s FAQ (Logistics & Compliance Focus)
Q: What HS Tariff Code is normally used for a GE shipment?
A: Classification depends on the declared function. Industrial communication boards may be reviewed under HS categories such as 8471.80, 8538, or related electronic assembly classifications depending on the importing authority. Confirm the final Harmonized System code with your customs broker before export.
Q: Does the Country of Origin affect acceptance of this spare module?
A: Yes. COO documentation supports import clearance, traceability, and customer audit records. Legacy GE Fanuc hardware may have different manufacturing origins depending on production period, so verify the label and certificate documentation.
Q: Should this VME board ship with additional insurance coverage?
A: Recommended. The contains optical transceivers, multilayer PCB assemblies, and legacy components that may have limited replacement availability. Insure shipments against impact, moisture exposure, and loss.
Q: Does the include the latest firmware pre-loaded?
A: Firmware status depends on the exact hardware revision and supplier condition. Confirm the board revision, memory configuration, and installed software package before deployment because compatibility with existing reflective memory drivers must be maintained.
