BENTLY 330103-00-06-10-01-00 | Genuine Machinery Asset

Description

1. BENTLY 330103-00-06-10-01-00 | Genuine Machinery Asset

Unboxing & Physical Snapshot

• Brand & Model: Bently Nevada 330103-00-06-10-01-00
• Product Type: 3300 XL 8 mm Proximity Probe for shaft vibration and position monitoring applications. This configuration uses an M10 × 1 threaded body, 60 mm case length, 1.0 m cable, and miniature coaxial ClickLoc connector.
• Physical Dimensions (Approximate W × H × D):
  • Probe tip diameter: 8 mm
  • Mounting thread: M10 × 1
  • Case length option: 60 mm
  • Cable length: 1.0 meter
  • Connector: Miniature coaxial ClickLoc type
• Estimated Shipping Weight: Approximately 0.08–0.32 kg, depending on packaging method and whether measured as probe-only or system component.
• What’s in the Box:
  • Bently Nevada 330103-00-06-10-01-00 proximity probe
  • Integrated standard cable
  • Miniature coaxial ClickLoc connector with protector
  • Product identification label
  • Protective packaging
  • OEM documentation when supplied

Product Introduction

Structure C — Compliance Hook

The Bently Nevada 330103-00-06-10-01-00 is a precision machinery protection component where exact configuration control is mandatory. Probe diameter, thread type, cable length, and connector style all influence the final measurement loop performance. A replacement that appears mechanically similar may still produce incorrect vibration readings if the electrical characteristics do not match the installed system.

This 3300 XL 8 mm proximity probe is installed as part of a complete eddy-current sensing system consisting of the probe, extension cable arrangement where applicable, and Proximitor sensor. The probe provides non-contact measurement of shaft displacement for rotating machinery monitoring applications (—including turbines, compressors, and large industrial rotating equipment). Inspect the stainless-steel body, cable jacket, and connector before installation.

Core Technical Specifications

BENTLY 330103-00-06-10-01-00

Specifications are based on the Bently Nevada 3300 XL 8 mm Proximity Transducer family. Verify the installed system length and Proximitor compatibility before replacement.

? Global Compliance & Industry Certifications

Expected regulatory approvals and compliance considerations for this machinery monitoring sensor include:

• CE Mark — confirms compliance with applicable EMC and safety requirements when installed within an approved system.
• ATEX/IECEx Approval Options — available for selected 3300 XL probe configurations when ordered with the required hazardous-area approval option.
• UL/cUL Recognition — may apply depending on the complete monitoring system and installation arrangement.
• RoHS Compliance — dependent on manufacturing revision and production date.
• Marine approvals (DNV GL) — only applicable to specifically certified machinery monitoring packages.

ATEX/IECEx certification matters because proximity probes may be installed near rotating equipment operating in classified hazardous environments. The approved sensing chain helps reduce ignition risk from electrical equipment installed near combustible gases or vapors.

Verify specific lot certifications with OEM.

? Long-Term Storage & Asset Preservation Guide

Keep the 330103-00-06-10-01-00 sealed inside the original anti-static (ESD) packaging until required for installation. Protect the probe tip and ClickLoc connector from dust, moisture, and mechanical impact.

Maintain warehouse humidity below 60% RH. The probe electronics are sealed, but connector surfaces and cable materials can degrade during prolonged exposure to uncontrolled environments (especially near salt air or chemical storage areas).

Inspect before deployment. Check the M10 × 1 threads, stainless-steel housing, cable jacket, and connector protector. Never install a probe with cracked insulation or damaged threads; these defects can compromise signal integrity.

Physical Installation Prerequisites

• Install only with compatible Bently Nevada 3300 XL Proximitor systems.
• Confirm the M10 × 1 mounting interface matches the existing machine installation.
• Verify total system length requirements before replacement.
• Maintain proper probe gap adjustment according to OEM installation procedures.
• Route probe cable away from high-voltage conductors and sources of electrical interference.
• Protect the ClickLoc connector from moisture and mechanical loading.
• Ensure the mounting surface provides a stable reference point to the bearing housing.

Maintain the recommended minimum cable bend radius of approximately 25.4 mm (1 inch) to prevent long-term cable stress.

Buyer’s FAQ (Logistics & Compliance Focus)

Q1. What HS Tariff Code is commonly used for the Bently Nevada 330103-00-06-10-01-00?

A: The final Harmonized System classification depends on the importing country’s customs rules and the declared function of the sensor. Some suppliers classify this type of industrial monitoring component under electrical control or measuring equipment categories, but the importer should confirm the correct HS code with a customs broker.

Q2. Does Country of Origin affect this spare sensor?

A: Yes. COO affects customs clearance, duty assessment, and audit traceability. Maintain the original product label, supplier documentation, serial records, and incoming inspection report with the spare asset file.

Q3. Is shipping insurance recommended for this proximity probe?

A: Recommended. The probe body is compact, but damage to the connector, cable jacket, or threaded section can prevent installation. Use ESD packaging, impact protection, and replacement-value freight coverage.

Q4. Does the 330103-00-06-10-01-00 include firmware?

A: No. The probe itself does not contain user-loadable firmware. Signal processing and configuration are handled by the associated Proximitor sensor and machinery monitoring system. Verify the complete probe/cable/Proximitor combination before commissioning.
