1. ELAU ISH100/30025 | High Precision Automation Motor

2. At-A-Glance Executive Brief

• Model: ELAU ISH100/30025/0/0/00/0/00/00/00
• Series: ELAU PacDrive Servo Motor Family
• Part Type: Synchronous AC Servo Motor
• Core Function: Converts electrical drive commands into controlled rotary motion for precision automation axes.
• Key Specifications:
  • ISH100 frame size servo motor.
  • Rated torque class: approximately 3 Nm.
  • Designed for PacDrive motion control systems.
  • Integrated feedback system.
  • Suitable for packaging, handling, and machine automation applications.
• Typical Procurement Category: Servo drive system spare, machine automation replacement motor, legacy ELAU motion component.

3. Product Introduction

Mounted directly on machine axes, the ELAU ISH100/30025/0/0/00/0/00/00/00 servo motor provides the mechanical movement required by PacDrive-based automation systems. When a servo motor fails, production issues usually appear as axis positioning errors, excessive following deviation, or unexpected machine stops. In field deployments, engineers check the motor, drive controller, feedback cable, and mechanical coupling together because the failure source is not always inside the motor assembly.

The ISH100 series was developed for high-accuracy industrial motion applications where repeatable positioning and dynamic response are required. This motor family is commonly associated with Schneider Electric’s PacDrive ecosystem after the ELAU integration (which is important when reviewing legacy machine documentation). Exact performance depends on encoder option, winding configuration, and drive compatibility.

4. Core Technical Specifications

Parameter	Value
Manufacturer	ELAU
Model Number	ISH100/30025/0/0/00/0/00/00/00
Product Type	AC Synchronous Servo Motor
Series	ISH100
Rated Torque	Approx. 3 Nm
Motor Frame Size	100 mm
Motor Speed	Application dependent
Feedback System	Integrated encoder (option dependent)
Motor Technology	Permanent magnet synchronous motor
Protection Rating	Typically IP65 (verify nameplate)
Cooling Method	Natural convection
Mounting Type	Flange mounting
Shaft Design	Machine coupling interface
Application	Packaging and industrial automation
Drive Compatibility	ELAU PacDrive servo amplifiers
Operating Environment	Industrial machine installation
Weight	Approx. 5–8 kg depending on options

ELAU ISH100/30025

5. Application Scenarios & Pain Points

On packaging machines running continuous cycles, the ISH100 servo motor controls positioning movements where even small feedback errors can interrupt production.

For food and pharmaceutical automation equipment, precise servo response supports synchronized axes operating under strict repeatability requirements.

During machine retrofit projects, ELAU motors are often retained because replacing the complete motion architecture can require extensive mechanical and software changes.

At facilities with older PacDrive installations, maintaining a tested spare motor reduces recovery time when production equipment experiences axis faults.

Without a compatible feedback motor, the servo drive may report positioning errors even when the drive electronics remain functional.

6. Common Error Codes & Diagnostic Symptoms

Symptom/Code: Following error / position deviation alarm
→ Diagnosis: Possible encoder feedback issue, mechanical overload, coupling failure, or motor winding problem.
→ Action: Inspect mechanical movement and feedback wiring, then replace the ISH100 motor if internal failure is confirmed.

Symptom/Code: Motor over-temperature warning
→ Diagnosis: Possible excessive load, insufficient cooling, bearing wear, or winding degradation.
→ Action: Check operating conditions and replace the motor if thermal damage is detected.

Symptom/Code: Encoder communication fault
→ Diagnosis: Possible feedback cable damage, connector contamination, or encoder failure.
→ Action: Verify cable integrity and replace the servo motor assembly if required.

7. Cross-Reference & Lifecycle Migration

• Compatible Platform: ELAU PacDrive motion control systems.
• Related Product Family: ISH100 servo motor series.
• Replacement Considerations:
  • Confirm motor winding specification.
  • Match encoder type.
  • Verify flange dimensions.
  • Confirm shaft configuration.
  • Check servo amplifier compatibility.
• Firmware Requirement:
  The motor itself normally does not contain application firmware. Drive parameters, motor identification data, and controller configuration should be verified after replacement.
• Lifecycle Status: Legacy / Controlled Spare.
  • Maintain replacement stock for existing PacDrive machines.
  • Preserve motor parameters and machine backup files before removing the original unit.

8. Field Engineer’s Tech Notes (Anti-Pitfall Guide)

1. Do not install a visually similar ISH motor without checking the complete order code.
   Encoder and winding variations can make physically identical motors electrically incompatible.
2. Protect the feedback connector during installation.
   Damaged encoder pins can create faults that look like drive or motor failures.
3. Record the original motor parameters before removal.
   Servo systems may require stored identification values or tuning adjustments after replacement.

9. Strict QA & Testing SOP

Step 1 — Incoming Inspection

• Verify ELAU label and complete ordering code.
• Record serial number and motor revision.
• Inspect shaft, flange, and connectors.

Step 2 — Mechanical Inspection

• Check shaft rotation.
• Inspect bearings for abnormal noise.
• Verify mounting surface condition.

Step 3 — Electrical Testing

• Measure winding resistance.
• Check insulation condition.
• Verify feedback connector continuity.

Step 4 — Functional Rig Testing

• Connect to compatible PacDrive servo amplifier.
• Verify encoder feedback.
• Confirm motor rotation.
• Check torque and response behavior.

Step 5 — Packaging Control

• Protect shaft and connectors.
• Use shock-resistant packaging.
• Attach inspection documentation.

Test videos are available for verification procedures when required.

10. Buyer’s FAQ (Dynamic Q&A)

Q: Can the ELAU ISH100/30025 servo motor be replaced while the machine is running?

A: No. Servo motor replacement requires machine shutdown, power isolation, and mechanical safety procedures before removal.

Q: How do I confirm this is the correct ISH100 motor variant?

A: Verify the complete order code, encoder option, winding data, flange size, shaft design, and compatibility with the installed PacDrive amplifier.

Q: Does this servo motor include the machine motion program?

A: No. The motor provides mechanical motion only. Motion parameters and application programs remain in the PacDrive controller and drive system.

Q: What documentation should be requested before purchasing?

A: Request product photos, nameplate details, test records, condition information, and warranty terms. Servo motors should be verified by electrical and mechanical testing rather than appearance alone.

Procurement Note: The ELAU ISH100/30025/0/0/00/0/00/00/00 should be stored as a controlled motion spare. Keep the motor together with drive parameters, encoder details, and machine-axis documentation to reduce commissioning time after replacement.
