EPRO PR6424/010-130+CON011 | OEM Shaft Vibration Sensor

Description

1. EPRO PR6424/010-130+CON011 | OEM Shaft Vibration Sensor

Unboxing & Physical Snapshot

• Brand & Model: EPRO PR6424/010-130 + CON011
• Product Type: 16 mm Eddy Current Sensor System consisting of a PR6424 non-contact displacement probe paired with a CON011 signal converter. Designed for shaft vibration, axial/radial displacement, position, eccentricity, and speed/key measurement on critical rotating machinery.
• Physical Dimensions (Approximate W × H × D):
  • PR6424 Probe:
    • Probe diameter: 16 mm
    • Sensor body length: approximately 52.5 mm + configuration length
    • Thread: M18 × 1.5
    • Cable: PTFE insulated cable, typical system lengths available from 4 m to 10 m depending on configuration
  • CON011 Converter:
    • Approximately 75 × 59 × 100 mm
    • Aluminum housing with panel mounting arrangement
• Estimated Shipping Weight: Approximately 0.8–1.0 kg including probe, converter, connectors, and protective packaging. The probe assembly itself is approximately 200 g without armor; the converter is approximately 600 g.
• What’s in the Box:
  • EPRO PR6424/010-130 eddy current probe
  • EPRO CON011 signal converter
  • LEMO connection interface
  • Probe identification label
  • Mounting hardware where supplied
  • ESD and moisture protective packaging
  • OEM documentation when included

Product Introduction

Structure C — Compliance Hook

The EPRO PR6424/010-130+CON011 measurement chain is a controlled machinery protection asset where probe and converter matching is essential. The sensor and converter are calibrated as a complete measuring system; replacing only one component without checking compatibility can introduce measurement errors in critical rotating equipment protection loops.

This 16 mm eddy current system is installed on turbines, compressors, pumps, and other rotating machinery where non-contact shaft measurement is required. The probe uses an eddy current principle to detect metallic target movement, while the converts the probe signal into a usable voltage output for monitoring equipment (—a configuration commonly maintained under machinery protection programs following API 670 practices). Inspect the probe tip, PTFE cable, LEMO connector, and converter housing before installation.

Core Technical Specifications

EPRO PR6424/010-130+CON011

Specifications are based on and technical documentation. Confirm exact measuring range, converter variant, and hazardous-area configuration before installation.

? Global Compliance & Industry Certifications

Expected regulatory approvals and compliance considerations for the EPRO /010-130+ system include:

• CE Mark — applicable for electromagnetic compatibility and safety compliance.
• ATEX Approval — available depending on converter, barrier, and installation configuration.
• IECEx Compatibility — dependent on the approved hazardous-area measurement chain.
• CSA Approvals — available for certain configurations.
• RoHS Compliance — dependent on production revision.
• Marine approvals (DNV GL) — applicable only when included in a certified marine machinery monitoring package.

ATEX/IECEx certification is important because these sensors are frequently installed near turbines and compressors operating in hazardous locations. Approved measurement chains help maintain electrical safety requirements where explosive atmospheres may exist.

Verify specific lot certifications with OEM.

? Long-Term Storage & Asset Preservation Guide

Keep the probe and converter sealed in their original ESD packaging until installation. Protect the LEMO connector and probe cable end from dust and moisture intrusion.

Maintain warehouse humidity below 60% RH. Connector corrosion is a common storage issue, especially for instrumentation installed in coastal or chemical processing environments.

Inspect before deployment. Check the stainless-steel probe sleeve, M18 × 1.5 threads, PTFE cable jacket, converter housing, and mounting screws. Do not install a probe with damaged insulation or connector contamination (small defects can create unstable vibration readings).

Physical Installation Prerequisites

• Install the probe only with the matched .
• Verify mounting thread compatibility: M18 × 1.5.
• Maintain correct probe gap according to the approved machine drawing.
• Provide sufficient clearance around the converter housing for heat dissipation.
• Maintain approximately 50 mm cabinet clearance around converter ventilation areas where practical.
• Use shielded instrumentation cable practices according to site standards.
• Verify grounding and signal reference connections before commissioning.
• Protect the LEMO connector from mechanical stress and moisture.

Do not modify probe cable length without engineering review. Cable characteristics are part of the calibrated measurement chain.

Buyer’s FAQ (Logistics & Compliance Focus)

Q1. What HS Tariff Code is commonly used for the EPRO /010-130+?

A: The final Harmonized System classification depends on the importing country’s customs interpretation and declared function. Eddy current measurement systems are generally reviewed under electrical measuring or monitoring instrument categories. Confirm the final HS code with your customs broker before export.

Q2. Does Country of Origin affect acceptance of this EPRO sensor system?

A: Yes. COO documentation may affect customs duties, customer qualification requirements, and audit traceability. Maintain supplier declarations, serial records, calibration information, and original labels.

Q3. Is shipping insurance recommended for this probe and converter set?

A: Recommended. The probe tip, cable assembly, and LEMO connector are precision components. Use ESD protection, impact-resistant packaging, and replacement-value freight insurance.

Q4. Does the /010-130+ include firmware?

A: No. The probe and converter are hardware measurement components and do not contain user firmware. Verify calibration compatibility, converter matching, and monitoring system settings before commissioning.
