GE 0880001-01 | 10.4″ QuickPanel Monochrome HMI

• Model & Brand: GE / Total Control Products 0880001-01, identified in the GE QuickPanel hardware reference as a 10.5-inch monochrome QuickPanel. Current legacy-part records cross-reference it to QPI2D100L2P-F / QPI-2D100-L2P.
• Physical Dimensions: Approximately 12.5 × 9.6 × 3.0 in (31.8 × 24.4 × 7.6 cm) based on the published shipping dimensions for the cross-referenced QPI2D100L2P-F assembly.
• Estimated Shipping Weight: Approximately 3.0 kg / 6.6 lb according to the same published shipping record. Treat this as a packed-shipment reference rather than a bare-panel net weight.
• What’s in the Box: The normal spare is the QuickPanel operator interface. Mounting hardware, gasket, cables, manuals, and replacement accessories should be confirmed separately against the actual quotation and packing list.
• Display Type: 10.4-inch monochrome LCD in current legacy-part records; GE’s hardware reference describes the catalog position as a 10.5-inch Mono QuickPanel. The discrepancy is a documentation-generation convention, not evidence of two different model numbers.
• Power: 24 VDC.
• Asset Identity: Preserve both 0880001-01 and the cross-reference QPI-2D100-L2P / QPI2D100L2P-F in the warehouse record.

Product Introduction

For legacy machine panels, the first physical question is not whether a replacement screen powers up. It is whether the replacement preserves the original panel cutout, operator-interface architecture, power arrangement, and mounting envelope. GE’s QuickPanel Hardware Reference places 0880001-01 in the 10.5-inch monochrome family, while current cross-reference records identify it with QPI2D100L2P-F, a 24 VDC monochrome operator interface.

This is an older generation of QuickPanel hardware. Current legacy-equipment records mark the QPI-2D100-L2P family as discontinued by the manufacturer, so procurement should focus on exact identity, physical condition, configuration retention, and application compatibility rather than assuming new production remains available.

Core Technical Specifications

GE’s historical hardware reference identifies 0880001-01 as the 10.5-inch monochrome product and documents UL 4X/12 and IP65 family protection. Current cross-reference data identifies the same 0880001-01 number with QPI2D100L2P-F and reports 24 VDC operation.

Power and heat note: A reliable OEM wattage figure for this exact legacy identifier was not established from the reviewed sources. Do not insert a generic 15–20 W figure into an approved cabinet thermal calculation without the unit’s applicable hardware documentation.

GE 0880001-01

🚨 Global Compliance & Industry Certifications

The strongest certification evidence located for 0880001-01 comes from GE’s historical QuickPanel documentation.

• UL 4X/12: GE’s QuickPanel Hardware Reference lists 0880001-01 within the QuickPanel family and associates the model with UL 4X/12 protection information.
• IP65: The same GE reference associates the relevant product family with IP65 front/enclosure protection.
• UL / cUL: Historical QuickPanel documentation identifies UL/CUL approvals across relevant operator-interface models, although the exact approval scope should be matched to the 0880001-01 nameplate and revision.
• CE: Do not automatically apply CE to this exact model from unrelated QuickPanel variants. The reviewed historical table shows different approval combinations for different panel models.
• ATEX / IECEx: No reliable exact certificate was established for 0880001-01 during this verification. Do not advertise the unit as independently ATEX- or IECEx-certified.
• Marine approvals: DNV, ABS, or other marine certification was not verified for this exact identifier.

The UL 4X/12 designation matters because it provides a defined enclosure/protection classification relevant to industrial panel applications. It does not mean that every installation environment or hazardous-area classification is automatically permitted.

Verify specific lot certifications with OEM.

🚨 Long-Term Storage & Asset Preservation Guide

Protect the LCD and front bezel during storage. The display face should remain covered and isolated from pressure, impact, and abrasive packaging material. Do not stack heavy cartons directly on the front panel.

Keep the unit in controlled ESD packaging. Although the operator interface is a complete enclosed assembly, its connectors and internal electronics remain vulnerable to ESD and contamination when the rear enclosure is exposed. Maintain the original anti-static packaging where available.

Control moisture and temperature cycling. The exact long-term storage limits for 0880001-01 were not reliably established from the OEM material reviewed here. Avoid condensation, high humidity, and repeated thermal cycling; allow a cold packaged unit to reach room temperature before opening (especially after air freight).

For legacy HMI inventory, retain the original label, cross-reference information, configuration media, mounting accessories, and service history. An old operator panel without its associated application/configuration files can be substantially less useful than the hardware alone.

Physical Installation Prerequisites

The IC/part identifier 0880001-01 corresponds to a QuickPanel operator-interface assembly, not a rack-mounted PLC card. Installation therefore depends on panel cutout dimensions, enclosure construction, power wiring, operator access, and rear-side cable clearance.

Before installation:

• Verify the replacement against the exact 0880001-01 nameplate and the installed QPI-2D100-L2P family reference.
• Measure the existing panel cutout before removal.
• Inspect any mounting brackets, gasket, retaining hardware, and threaded fasteners for deformation.
• Maintain enough rear clearance for the 24 VDC power connection and communication cabling.
• Avoid routing power and signal wiring directly across ventilation openings or against heat-producing equipment.
• Provide protective grounding and cabinet bonding in accordance with the panel design.
• Use ESD precautions whenever the rear enclosure or connectors are exposed.
• Check the exact mounting arrangement against the historical QuickPanel installation documentation.

One important point: published shipping dimensions of 31.8 × 24.4 × 7.6 cm describe the shipment envelope, not necessarily the exact panel cutout. Do not machine a replacement opening from shipping dimensions alone.

Buyer’s FAQ

Q1. What HS tariff code should be used for 0880001-01?

A current legacy-equipment record for the cross-referenced lists 8531200020 as its tariff code.

Use this as an indicative U.S. classification only. The importing country’s tariff schedule and customs interpretation can differ, so the final code should be validated by the importer or customs broker.

Q2. What Country of Origin should be declared?

A current cross-reference record lists the United States as the country of manufacture for the / 0880001-01 family.

For formal trade documentation, verify the physical unit and supplier COO declaration. Do not infer manufacturing origin from the current warehouse or shipping location.

Q3. Should I insure a shipment of one 0880001-01?

Insurance is worth considering when the unit supports a production-critical operator station. Published shipping data puts the packed shipment around 3.0 kg, but the operational significance of a damaged legacy HMI can exceed the item’s physical weight by a large margin.

Use rigid cushioning around the display face, document the front bezel and rear connectors before dispatch, and retain the serial/revision record with the packing list.

Q4. Does the unit arrive with the latest firmware pre-loaded?

Do not assume that it does. The 0880001-01/QPI2D100L2P family is discontinued, and historical QuickPanel units can contain different software or configuration states.

For a replacement order, specify the exact hardware identifier and request the available firmware/configuration information from the seller. The engineering question is not simply whether the panel powers on; the replacement must also support the application’s stored QuickPanel configuration and communications setup.

Lifecycle & Asset-Control Note

GE 0880001-01 is a legacy QuickPanel operator interface and is listed in current secondary-market records as discontinued. The documented cross-reference to is important when searching legacy inventory, but the exact front-panel hardware, LCD condition, label, and software state should still be checked before substitution.

For controlled spare inventory, record 0880001-01 + cross-reference + hardware revision + display condition + configuration/firmware information + certification evidence as separate asset fields.
