GE CR215GH12+CR215GFE | Industrial Limit Switch Assembly

1. GE CR215GH12+CR215GFE | Industrial Limit Switch Assembly

Unboxing & Physical Snapshot

• Model & Brand: GE CR215GH12 + CR215GFE assembly
• Product Type: GE CR Series industrial motor control component assembly combining CR215GH12 motor control hardware and CR215GFE programmable limit switch component.
• Approximate Physical Dimensions (W × H × D): Approximately 140 × 120 × 80 mm (final dimensions depend on complete mounted assembly configuration)
• Estimated Shipping Weight: Approximately 0.8-1.2 kg (1.8-2.6 lb), including protective packaging
• What’s in the Box:
  • GE CR215GH12 motor control component
  • GE CR215GFE programmable limit switch assembly
  • Mounting hardware where supplied
  • Protective packaging materials
  • Product identification labels
  • Technical documentation (availability depends on source condition)

Product Introduction

The correct use of GE CR215GH12 and CR215GFE hardware begins with identity control. Motor control assemblies installed in industrial equipment require exact replacement verification because mechanical fit, contact arrangement, enclosure protection, and electrical ratings must remain consistent with the original design. (This matters during reliability audits where undocumented substitutions can create compliance findings.)

The CR215GH12 belongs to the GE CR motor control product family, while the CR215GFE is identified as a programmable limit switch component used within industrial control applications. These components are commonly encountered in legacy machinery where maintaining the original control sequence is more practical than redesigning the entire panel. Inspect the contact blocks, mounting surfaces, terminal markings, and enclosure seals before installation.

Core Technical Specifications

GE CR215GH12+CR215GFE

? Global Compliance & Industry Certifications

Expected regulatory considerations for GE CR Series motor control hardware include:

• UL Listed / UL Recognized: Applicable versions may carry UL approvals for industrial control equipment.
• CSA Certification: Certain North American industrial control variants may include CSA recognition.
• CE Mark: Applicable only for specific manufactured versions and intended markets.
• RoHS Compliance: Depends on manufacturing date and product revision.
• ATEX / IECEx: Not typically associated directly with this component unless installed within a certified hazardous-area assembly.
• Marine Approvals (DNV GL): Only applicable for specially certified equipment packages.

For industrial panels operating in hazardous locations, certification continuity is critical. A replacement contactor or switching component without the correct approval markings can invalidate the original enclosure certification.

Verify specific lot certifications with OEM.

? Long-Term Storage & Asset Preservation Guide

Store the GE and assembly in a dry cabinet environment with humidity controlled below 60%. Moisture exposure can degrade contact surfaces, insulation materials, and mechanical movement components over extended storage periods.

Keep the assembly inside its original packaging or an ESD-safe protective container. Do not allow dust contamination around the contact surfaces, terminal screws, or mechanical actuator components (small particles can create intermittent switching failures).

Inspect stored units annually. Check the terminal hardware for corrosion, confirm that moving mechanisms operate freely, and verify that no plastic housings show cracking from temperature cycling.

Physical Installation Prerequisites

• Install only in the equipment configuration specified by the original machine design.
• Confirm mounting clearance around the actuator mechanism and terminal connections.
• Maintain sufficient cabinet spacing for heat dissipation generated by energized contacts.
• Provide protective earth grounding through the approved panel grounding structure.
• Verify terminal torque values before energization.
• Inspect mechanical alignment between the control section and limit switch assembly before startup.
• Keep at least 50 mm clearance around ventilation paths and heat-producing components where cabinet design permits.

GE CR215GH12+CR215GFE

Buyer’s FAQ (Logistics & Compliance Focus)

Q: What HS Tariff Code should be used when shipping this GE assembly internationally?

A: Classification depends on the declared function. Industrial switching and motor control components may fall under HS categories such as 8536 or related electrical apparatus classifications. Customs authorities may interpret the classification differently based on assembly configuration, so confirm the final code with your customs broker.

Q: Does Country of Origin affect replacement approval?

A: Yes. The COO affects import documentation, warranty evaluation, and traceability records. Legacy GE industrial components may have different manufacturing locations across production years, so verify the label information before receiving inspection.

Q: Should I purchase shipping insurance for this part?

A: Recommended. These assemblies contain precision mechanical contacts, molded insulating materials, and legacy components that may have limited replacement availability. Protect shipments against impact damage, moisture exposure, and loss.

Q: Does the + assembly include the latest firmware?

A: Firmware availability depends on the specific configuration. Many legacy programmable limit switch assemblies are hardware-focused devices rather than modern firmware-managed modules. Confirm revision level and configuration data before installation.
