- Honeywell CC-TAON11 | Series-C Redundant Terminal Unit
Unboxing & Physical Snapshot
- Model & Brand: Honeywell CC-TAON11 Series-C IOTA assembly for high-level analog output applications in the Experion PKS Distributed Control System. The CC-TAON11 is the 12-inch redundant IOTA version used with the CC-PAON01 analog output module.
- Approximate Physical Dimensions: Approximately 7.5 × 7.4 × 2.6 in. (191 × 188 × 65 mm). Dimensions vary slightly depending on terminal hardware and packaging configuration.
- Estimated Shipping Weight: Approximately 1.0 lb (0.45 kg) including protective packaging.
- What’s in the Box:
- Honeywell CC-TAON11 redundant Analog Output IOTA assembly
- Terminal connection hardware (configuration dependent)
- Anti-static (ESD) shielding bag
- Protective foam packaging
- Identification label
- Documentation when supplied
Product Introduction
The Honeywell CC-TAON11 mounts into the Experion Series-C I/O architecture as the physical termination interface between field wiring and the analog output electronics module. This 12-inch IOTA design supports redundant analog output configurations, providing the terminal structure and protection interface required for process control outputs (which is important for control valves, actuators, and critical final elements).
This assembly is not a standalone controller. It works with the appropriate Series-C analog output module, creating a complete signal path from controller logic to field equipment. Inspect the terminal blocks, connector pins, and mounting hardware before installation. A damaged termination assembly can introduce intermittent output faults that appear to be software or instrument problems.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Honeywell |
| Model Number | CC-TAON11 |
| Product Type | Analog Output IOTA Assembly |
| System Platform | Honeywell Experion PKS Series-C I/O |
| Associated Module | CC-PAON01 High-Level Analog Output Module |
| Configuration | Redundant 12-inch IOTA |
| Output Channels | 16 analog output channels |
| Output Signal | 4–20 mA |
| HART Support | Non-HART configuration |
| Output Load Capability | Up to 800 Ω (24 VDC supply conditions) |
| Maximum Output Compliance Voltage | 16 V |
| Output Current Range | 0 mA, 2.9 mA to 21.1 mA |
| Output Ripple | Less than 100 mV peak-to-peak across 250 Ω load |
| Temperature Drift | 0.005% of full scale/°C |
| Module Protection | Short-circuit protection |
| Hazardous Area Capability | Division 2 / Zone 2 applications when installed in approved configuration |
| Mounting Method | Series-C I/O carrier installation |
Honeywell CC-TAON11
Global Compliance & Industry Certifications
Expected regulatory approvals and compliance considerations for the Honeywell CC- include:
- CE Mark compliance for applicable Experion Series-C installations
- UL/cUL recognition where applicable to the complete control system assembly
- Class I Division 2 non-incendive suitability when installed according to approved system requirements
- Zone 2 hazardous-area suitability through certified system configurations
- ATEX/IECEx applicability when used with approved hazardous-area assemblies
- RoHS compliance depending on manufacturing revision
- Marine approvals such as DNV GL only for specifically certified project installations
The Class I Division 2 rating is significant because it confirms the equipment interface is designed for locations where flammable gases may occasionally exist, reducing ignition risk when installed within the approved limits.
Verify specific lot certifications with OEM.
Long-Term Storage & Asset Preservation Guide
Keep the CC- sealed in its original anti-static (ESD) packaging during storage. The terminal contacts, connector interfaces, and protection components should remain protected from dust and moisture.
Maintain warehouse humidity below 60% RH. Avoid storage near chemical processing areas, battery rooms, or environments with corrosive vapors because oxidation on terminal surfaces can create unstable analog output signals.
Inspect before deployment. Check terminal screws, connector alignment, mounting clips, and identification labels. Record the hardware revision and serial information before releasing the spare to the maintenance team.
Physical Installation Prerequisites
- Install only within the approved Honeywell Series-C I/O carrier system.
- Use the compatible CC-PAON01 analog output electronics module.
- Verify redundant wiring arrangement before installation.
- Maintain approximately 50 mm clearance above and below cabinet ventilation paths where practical.
- Confirm cabinet grounding and protective earth bonding.
- Inspect terminal blocks and connector seating before applying power.
- Verify field wiring polarity and loop requirements before commissioning.
Buyer’s FAQ (Logistics & Compliance Focus)
Q: What HS Tariff Code is commonly used for the Honeywell CC-?
A: The CC- is generally evaluated under HS classifications covering electrical control equipment and industrial automation assemblies, commonly within HS 8537 categories. Final classification depends on the importing country’s customs interpretation and declared function.
Q: Does Country of Origin affect this Honeywell spare assembly?
A: Yes. COO documentation affects customs clearance, procurement records, and regulated industrial project documentation. Confirm that the Country of Origin on the commercial invoice matches supplier records and the equipment identification label.
Q: Should shipping insurance be included for this IOTA assembly?
A: Recommended. Although the assembly is lightweight, damage to terminal structures or connectors can delay commissioning. Use ESD packaging, impact protection, and documented receiving inspection procedures.
Q: Does the CC- include the latest firmware pre-loaded?
A: No. The CC- is a termination assembly and does not contain application firmware. Firmware compatibility is associated with the connected Series-C I/O module and Experion PKS system configuration. Verify module revision compatibility before installation.
