- AMAT 0190-26873 | Industrial Semiconductor Motion Board
Unboxing & Physical Snapshot
- Model & Brand: AMAT 0190-26873 (Applied Materials)
- Product Type: Semiconductor equipment motion control board based on Delta Tau Turbo PMAC2 / UMAC-CPCI motion controller architecture. It is used in Applied Materials semiconductor manufacturing platforms for precision multi-axis motion control applications such as wafer handling and positioning systems.
- Approximate Physical Dimensions (W × H × D):
- Approximately 160 × 100 × 30 mm (board dimensions may vary depending on carrier configuration).
- Estimated Shipping Weight:
- Board weight: approximately 0.3–0.5 kg
- Typical packaged shipping weight: 0.8–1.2 kg
- What’s in the Box:
- AMAT 0190-26873 motion controller board
- Delta Tau Turbo PMAC2-based control assembly
- Connector interface assembly (configuration dependent)
- Anti-static (ESD) shielding bag
- Protective foam packaging
- Product identification label
- Documentation when supplied
Product Introduction
The AMAT 0190-26873 is installed inside Applied Materials semiconductor process equipment where deterministic motion control is required for wafer transfer, positioning stages, and synchronized mechanical assemblies. The controller interfaces with servo systems, encoder feedback devices, and equipment-level sensors to maintain precise movement sequences inside fabrication tools (—which is critical because even small positioning errors can affect wafer handling reliability).
This board is a controlled semiconductor spare, not a general-purpose industrial CPU card. Confirm the exact AMAT part number, Delta Tau hardware revision, firmware image, and machine configuration before installation. Inspect the CPCI edge connector, PCB surface, mounting points, and protective coating carefully. Semiconductor equipment often operates continuously for long production cycles, so replacement traceability matters.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Applied Materials (AMAT) |
| Part Number | 0190-26873 |
| Controller Architecture | Delta Tau Turbo PMAC2 |
| Module Type | Multi-axis motion controller board |
| Application | Semiconductor equipment motion control |
| Equipment Platforms | Applied Materials Centura / Endura / Producer family systems (application dependent) |
| Processor Architecture | Turbo PMAC2 DSP-based controller |
| Motion Control Capability | Multi-axis coordinated motion |
| Encoder Feedback | Supported through system interfaces |
| I/O Capability | Analog, digital, and motion feedback interfaces |
| Communication Interface | CPCI / embedded control interface |
| Analog Resolution | Up to 24-bit ADC (configuration dependent) |
| Sampling Rate | Up to approximately 10 kS/s per channel (configuration dependent) |
| Power Supply | Approximately 48 VDC system supply |
| Power Consumption | Approximately 35 W |
| Isolation | Up to 2500 Vrms channel-to-system isolation (configuration dependent) |
| Memory | Firmware and application parameter memory |
| Cooling Method | Passive conduction/convection cooling |
| Mounting | Embedded semiconductor equipment controller chassis |
AMAT 0190-26873
? Global Compliance & Industry Certifications
Expected regulatory considerations for the AMAT 0190-26873 include:
- CE Mark: Applicable when integrated into a compliant Applied Materials semiconductor equipment system.
- UL/cUL Listed: May apply at the equipment-system level depending on the final machine certification.
- ATEX / IECEx: Normally not a standalone hazardous-area device. Hazardous-area use requires the complete semiconductor tool installation to have appropriate certification.
- Marine Approvals (DNV GL): Generally not applicable unless installed in a specially certified marine manufacturing environment.
For semiconductor manufacturing equipment, compliance records usually focus on the complete tool rather than an individual motion board. Maintain equipment configuration records, replacement history, and revision tracking.
Verify specific lot certifications with OEM.
? Long-Term Storage & Asset Preservation Guide
Keep the AMAT 0190-26873 inside its original anti-static (ESD) shielding bag. Do not expose the connector edge or PCB surface unnecessarily.
Maintain warehouse humidity below 60% RH. High humidity can accelerate oxidation on edge connectors and degrade protective coatings on electronic assemblies.
Inspect stored boards every 12–24 months. Check the PCB coating, connector fingers, capacitors, mounting holes, and identification labels. Before installation, verify the firmware version and motion parameters against the equipment backup records.
Physical Installation Prerequisites
- Install the AMAT 0190-26873 only in the approved Applied Materials equipment controller chassis.
- Confirm compatibility with the existing Turbo PMAC2 configuration.
- Inspect CPCI connectors before insertion.
- Verify grounding straps and chassis bonding connections.
- Secure retaining hardware before equipment startup.
- Maintain cabinet airflow paths for electronic cooling.
- Leave approximately 50 mm clearance around ventilation areas where cabinet design requires convection cooling.
- Protect the board from ESD during handling.
- Perform axis calibration and motion verification after replacement.
Buyer’s FAQ (Logistics & Compliance Focus)
Q: What HS Tariff Code is commonly used for the AMAT 0190-26873?
A: Semiconductor equipment control boards are commonly reviewed under HS 8538 or related electronic control equipment classifications. Final classification depends on the importing country’s customs interpretation and declared function.
Q: Does Country of Origin (COO) affect importing this AMAT spare?
A: Yes. COO documentation supports customs clearance, import reporting, and semiconductor asset traceability. Ensure the COO shown on commercial documents matches available product records.
Q: Is shipping insurance recommended for this motion controller board?
A: Recommended. The board contains precision electronics, DSP processing hardware, and high-density connectors. Shock, moisture, or ESD exposure during transport may create failures that are not immediately visible.
Q: Does the AMAT 0190-26873 include the latest firmware pre-loaded?
A: Firmware depends on the board revision and previous service history. The replacement unit should be checked against the installed equipment image, motion parameters, and approved configuration backup before production use.
