GE SR469-P5-HI-A20-E | Authentic Asset with Compliance Documentation

Description

1. GE SR469-P5-HI-A20-E | Authentic Asset with Compliance Documentation

Unboxing & Physical Snapshot

• Brand & Model: GE SR469-P5-HI-A20-E Motor Management Relay
• Approximate Physical Dimensions (W × H × D): 144 × 144 × 185 mm (5.7 × 5.7 × 7.3 in)
• Estimated Shipping Weight: Approximately 2.8 kg (6.2 lb), excluding external protective packaging
• What’s in the Box:
  • GE SR469-P5-HI-A20-E relay
  • Panel mounting hardware with retaining clips
  • Installation manual (if supplied with factory packaging)
  • Factory identification labels and serial number tag
  • Protective packaging (ESD bag or molded foam, depending on production lot)

Product Introduction

Using the correct OEM protection relay is a compliance decision before it becomes a maintenance decision. Facilities operating critical motors depend on certified protection hardware because replacement devices must maintain the documented protection philosophy established during commissioning (particularly in regulated process industries where configuration records are audited).

The GE SR469-P5-HI-A20-E is intended for installation within industrial motor control centers and protection panels where continuous monitoring of motor operating conditions is required. Its front-mounted display, reinforced enclosure, and rear terminal assemblies allow integration into existing control cabinets without altering the original protection architecture (provided the replacement configuration matches the installed application). During asset verification, inspect the front membrane keypad, terminal screws, and enclosure corners for shipping damage before installation.

Core Technical Specifications

GE SR469-P5-HI-A20-E

? Global Compliance & Industry Certifications

Expected approvals for this class of industrial protection relay may include:

• CE Mark (European market compliance)
• UL Listed
• cUL Listed for Canada
• IEC 60255 protection relay compliance (product family dependent)
• RoHS compliance (production revision dependent)
• Marine approvals such as DNV GL for qualified variants (application dependent)
• ATEX or IECEx approvals are generally not standard for this relay itself because it is normally installed inside a certified control enclosure rather than directly within hazardous locations.

For facilities operating classified hazardous areas, the enclosure certification often carries equal importance. A Class I Division 2 or Zone-certified control cabinet helps prevent ignition of flammable gases by controlling ignition sources inside the enclosure (which becomes especially important during abnormal operating conditions).

Verify specific lot certifications with OEM documentation before regulatory inspections or project acceptance.

? Long-Term Storage & Asset Preservation Guide

Store this relay inside its original anti-static (ESD) shielding bag whenever possible. The factory packaging limits electrostatic discharge during warehouse handling and also reduces contamination of the terminal block contacts.

Maintain warehouse relative humidity below 60% while avoiding rapid temperature swings that produce condensation on the display window and internal circuit boards (condensation damage often goes unnoticed until commissioning). Temperature-controlled storage between approximately 10°C and 30°C is preferred for extended inventory.

Inspect the relay every 12 to 24 months. Confirm that the terminal screws remain corrosion-free, verify the LCD window has not yellowed, and examine the enclosure for deformation caused by improper pallet stacking. If backup battery components are installed on a particular hardware revision, inspect them according to the manufacturer’s maintenance recommendations before field deployment.

GE SR469-P5-HI-A20-E

Physical Installation Prerequisites

• Install the relay in a clean, dry control cabinet with adequate ventilation.
• Leave at least 50 mm (2 in.) of clearance above and below the unit to promote natural convection cooling.
• Ensure the panel cutout matches the specified mounting dimensions before inserting the enclosure.
• Tighten the retaining clips evenly to prevent distortion of the front bezel.
• Connect protective earth according to the installation manual and plant grounding philosophy.
• Route CT, VT, communication, and control wiring separately from high-current power conductors to minimize electrical noise (especially in variable frequency drive installations).
• Verify terminal torque values during commissioning to prevent loose connections after thermal cycling.

GE SR469-P5-HI-A20-E

Buyer’s FAQ (Logistics & Compliance Focus)

Q1. Which HS Tariff Code is typically used for international shipment?

A: Industrial motor protection relays such as the SR469-P5-HI-A20-E are commonly classified under HS headings within 8537 or 8536, depending on the importing country’s tariff interpretation and the declared product function. Final classification should always be confirmed by the customs broker and local customs authority before shipment.

Q2. Does the Country of Origin affect import documentation?

A: Yes. Country of Origin (COO) influences customs duty assessment, trade agreement eligibility, and documentation requirements. Always request the original COO declaration or Certificate of Origin when procurement policies or government contracts require traceability.

Q3. Is shipping insurance recommended for this relay?

A: Absolutely. Although the enclosure is mechanically durable, impacts can crack the LCD assembly, bend terminal blocks, or damage internal circuit boards without obvious external signs. Full replacement-value insurance and shock-resistant packaging are recommended for international freight.

Q4. Will the relay arrive with the latest firmware already installed?

A: Not necessarily. Firmware depends on the manufacturing date and warehouse inventory rotation. Before commissioning, verify the installed firmware revision against the project’s approved baseline and update it only in accordance with the site’s management-of-change (MOC) procedure and OEM guidance.
