Description
- ICS Triplex 9832 | Original TMR Termination Assembly
Unboxing & Physical Snapshot
- Model & Brand: ICS Triplex 9832
- Product Type: Trusted™ Analog Input Termination Assembly (TA) used with ICS Triplex Trusted safety systems. The T9832 provides field wiring termination for dual redundant analog input configurations and supports isolated field connections.
- Approximate Physical Dimensions (W × H × D):
- Approximately 42 × 166 × 118 mm
- Compact AADvance/Trusted style termination assembly format.
- Estimated Shipping Weight:
- Unit weight: approximately 0.2–0.3 kg
- Typical packaged shipping weight: 0.5–0.8 kg
- What’s in the Box:
- ICS Triplex T9832 Analog Input Termination Assembly
- Field wiring interface terminals
- Fuse protection components
- Product identification label
- Anti-static (ESD) shielding bag
- Protective packaging
- Documentation when supplied
Product Introduction
The ICS Triplex T9832 sits at the field termination layer of the Trusted safety system architecture. It provides the physical connection point between external analog instruments and the associated input modules, maintaining organized signal routing inside the control cabinet. The assembly supports dual configurations with isolated field connections (—which is important when maintaining separation between safety-related measurement loops).
This component does not perform signal processing by itself. Its role is electrical interface management. Inspect every terminal point, fuse position, and connector surface before installation. Incorrect wiring termination or damaged contacts can create measurement faults that may not appear until loop testing or process demand conditions occur.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | ICS Triplex |
| Model | T9832 |
| Product Family | Trusted™ Safety System |
| Module Type | Analog Input Termination Assembly |
| Application | Dual analog input field termination |
| Supported Input Channels | 16 field connections |
| Configuration Type | Dual isolated arrangement |
| Supported Input Modules | Two analog input modules |
| Field Wiring Capacity | Maximum conductor size approximately 1.31 mm² (16 AWG) |
| Wire Stripping Length | Approximately 6 mm |
| Input Protection | Channel fuse protection |
| Fuse Type | 50 mA, 125 V Type T fuse |
| Channel Isolation | Up to ±1.5 kVDC withstand for 1 minute |
| Power Consumption | Passive termination device |
| Heat Dissipation | Approximately 0.08 W per field loop |
| Processor | None |
| Firmware Memory | None |
| Communication Interface | Direct termination connection |
| Operating Temperature | System dependent |
| Storage Temperature | Typical industrial electronic storage range |
| Humidity | 5–95% RH non-condensing |
- ICS Triplex 9832
? Global Compliance & Industry Certifications
Expected regulatory considerations for the ICS Triplex T9832 include:
- CE Mark: Applicable when installed as part of a compliant Trusted safety system assembly meeting EMC requirements.
- UL/cUL Listed: May apply depending on the complete safety cabinet certification package.
- IEC 61508 Functional Safety: Relevant because the T9832 is installed within safety-related architectures supporting certified system configurations.
- ATEX / IECEx: The termination assembly is not normally a standalone hazardous-area certified device. Hazardous-area installation requires approved barriers, enclosure systems, and complete certification.
- Marine Approvals (DNV GL): Applicable only when integrated into approved marine automation systems.
The termination assembly directly affects field wiring integrity. During audits, verify terminal identification, fuse ratings, wiring records, and replacement history.
Verify specific lot certifications with OEM.
? Long-Term Storage & Asset Preservation Guide
Keep the sealed inside an anti-static (ESD) shielding bag during storage. Protect terminal contacts and fuse holders from dust, moisture, and airborne contaminants.
Maintain warehouse humidity below 60% RH. Corrosion at termination points can increase resistance and create unreliable analog measurements after commissioning.
Inspect stored assemblies every 12–24 months. Check terminal screws, fuse holders, connector surfaces, and plastic housing condition. Replace damaged fuses only with approved specifications before installation.
Physical Installation Prerequisites
- Install the only within the approved ICS Triplex Trusted system arrangement.
- Verify the termination assembly matches the installed analog input module configuration.
- Confirm field wiring numbers against approved drawings before energizing.
- Tighten terminal screws according to manufacturer specifications.
- Maintain cabinet ventilation paths and leave approximately 50 mm clearance around major airflow areas where required.
- Confirm cabinet protective earth grounding.
- Keep analog signal wiring separated from high-voltage switching cables.
- Verify fuse installation and channel identification before commissioning.
- ICS Triplex 9832
Buyer’s FAQ (Logistics & Compliance Focus)
Q: What HS Tariff Code is commonly used for the ICS Triplex ?
A: Industrial control termination assemblies are commonly reviewed under HS 8538 or related automation equipment component classifications. Final classification depends on customs interpretation and the importing country’s regulations.
Q: Does the Country of Origin (COO) affect acceptance of this spare part?
A: Yes. COO documentation supports customs clearance, import compliance, and maintenance traceability. Ensure the origin shown on the commercial invoice matches the product identification records.
Q: Is shipping insurance recommended for the ?
A: Recommended. Although it contains no processor electronics, damage to terminal blocks, fuse holders, or connector structures can prevent correct field installation.
Q: Does the ICS Triplex 9832 include firmware or require software loading?
A: No. The is a passive termination assembly and contains no processor, firmware, or application memory. Configuration applies to the connected Trusted input modules and controller system.
