ABB HL000986P0006 | ABB High Voltage Spare Part

Description

• Model: HL000986P0006
• Brand: ABB
• Part Type: High-voltage capacitor
• Capacitance: 4 µF
• Voltage Rating: 2800 VDC
• Current Rating: 70 A

Technical Introduction

The ABB HL000986P0006 is a high-voltage capacitor specified at 4 µF, 2800 VDC, and 70 A.

ABB catalog references identify HL000986P0006 specifically as a 4 µF / 2800 VDC / 70 A capacitor. The part appears within ABB’s HL000 series of power-electronics components, alongside DC-link, common-mode, EMC-filter, and other high-voltage converter components. Secondary industrial listings also associate the part with TPC FPX86-9345-B, which can be useful when cross-checking the physical component and equipment documentation.

Best Suited For

• ABB high-voltage converter maintenance
• Replacement of failed power-electronics capacitors
• Strategic spare inventory for legacy ABB drive systems

Core Technical Specifications

ABB HL000986P0006

The published ABB component catalog identifies HL000986P0006 as “CAPACITOR (CAPACITOR, 4UF, 2800VDC, 70A)”.

Please refer to the OEM datasheet and equipment documentation for complete ESR, ripple-current, temperature, insulation, mechanical, discharge, and mounting requirements.

Field Engineer’s Tech Notes

1. Treat this as a high-energy component. A 2800 VDC capacitor can retain a dangerous charge after equipment shutdown. Follow the applicable ABB discharge procedure, verify the DC bus is at a safe measured voltage, and observe the plant’s lockout/tagout requirements before handling.
2. Check the complete capacitor specification, not only capacitance. The 4 µF value and 2800 VDC rating must be matched with the installed circuit. Confirm terminal arrangement, physical dimensions, current/ripple requirements, and mounting before substitution. Do not replace it with a capacitor having a similar capacitance but a lower voltage or current rating.

Adaptive QA & Testing Protocol

For an HL000986P0006, incoming inspection focuses on the capacitor body, terminals, insulation surfaces, mounting features, identification markings, and evidence of swelling, cracking, leakage, corrosion, or mechanical impact.

Electrical verification should be performed with equipment appropriate for a 2800 VDC-rated capacitor. Capacitance and insulation characteristics can be checked against the applicable OEM limits using suitable test equipment. Where the capacitor is installed as part of a converter assembly, the surrounding DC-link circuit should also be inspected for evidence of overvoltage, excessive ripple current, thermal stress, or previous capacitor failure.

Inspection photographs, test reports, and available test videos can be provided upon request.

Buyer’s FAQ

What is the electrical rating of ABB ?

The published ABB component reference identifies it as a 4 µF capacitor rated at 2800 VDC and 70 A.

Is available new or refurbished?

Condition depends on the available inventory lot. New surplus, new old stock, and refurbished options may be available. Confirm the exact condition and electrical test status before purchase.

Can this capacitor be used as a generic 4 µF replacement?

Not automatically. The replacement must satisfy the complete application requirements, including voltage rating, current/ripple capability, physical configuration, insulation, terminals, and environmental conditions.

Can you provide inspection or test documentation?

Yes. Depending on the available unit and test equipment, inspection records, photographs, capacitance measurements, and other applicable test documentation can be provided upon request.
