1. Motorola MVME162P-344S | Legacy Automation CPU Unit

Unboxing & Physical Snapshot

• Brand & Model: Motorola MVME162P-344S
• Product Family: Motorola MVME162P VMEbus Embedded Controller Series.
• Product Type: 6U VME single-board computer (SBC) designed for embedded industrial computing applications.
• Configuration Identification: MVME162P-344S variant with:
  • 32 MHz Motorola MC68040 processor
  • 16 MB SDRAM
  • Four DMA IndustryPack interfaces
  • Two serial interfaces
  • SCSI interface
• Approximate Physical Dimensions:
  • Board only: approximately 233 × 160 × 16.8 mm
  • With front panel and connectors: approximately 262 × 188 × 20 mm
• Estimated Shipping Weight: Approximately 1.0–1.5 kg (2.2–3.3 lb) including ESD protection and transport packaging.
• Mounting Style: Double-height 6U VME rack installation using VME P1/P2 connectors.
• Processor Architecture: Motorola 68040 32-bit CPU platform.
• Board Features:
  • Multi-layer PCB assembly
  • Front aluminum faceplate
  • VMEbus interface connector
  • SCSI controller interface
  • IndustryPack expansion connectors
  • Battery-backed memory components
• Front Panel Features:
  • Status LEDs
  • Reset and abort controls
  • Serial communication access
  • Identification label
• What’s in the Box:
  • Motorola MVME162P-344S CPU board
  • Anti-static ESD shielding bag
  • Protective foam packaging
  • Documentation when supplied

Product Introduction

The Motorola MVME162P-344S mounts directly into a VMEbus chassis as the main processing board for embedded control systems. Its VME backplane connection, SCSI storage interface, and IndustryPack expansion capability allow older automation platforms, test systems, and industrial computers to continue operating without architectural replacement.

This board requires careful preservation handling. Check the VME connector fingers, battery-backed memory area, and socketed components before installation. Many systems remain operational decades after deployment, so maintaining original hardware condition is often more practical than redesigning the host system (which is common in long-life industrial installations).

Core Technical Specifications

Motorola MVME162P-344S

Global Compliance & Industry Certifications

Expected regulatory considerations for rola include:

• CE Mark — may apply when installed within a compliant VME chassis and system enclosure meeting EMC requirements.
• UL/cUL Recognition — generally evaluated at the complete equipment level rather than the individual legacy CPU board.
• RoHS Compliance — depends on production date and hardware revision because many boards predate modern environmental directives.
• IEC Industrial Equipment Practices — relevant when integrated into industrial automation or test equipment.
• ATEX/IECEx — the CPU board itself is not automatically approved for hazardous areas; certification depends on the complete enclosure and system design.
• Marine approvals (DNV GL, ABS, or LR) — applicable only when incorporated into a certified marine computing platform.

For legacy VME equipment, compliance documentation is often maintained at the machine or system level rather than at the individual replacement board level.

Verify specific lot certifications with OEM.
