1. Motorola MVME5500-0163 | Traceable VMEbus Processor

Unboxing & Physical Snapshot

• Model & Brand: Motorola MVME5500-0163
• Product Type: 6U VME64 Single Board Computer (SBC)
• Application: Embedded industrial computing controller designed for VME-based automation, telecommunications, test equipment, and long-life control systems. The MVME5500-0163 configuration includes a 1 GHz MPC7455 PowerPC processor, 512 MB ECC SDRAM, Flash memory, dual PCI/PMC expansion capability, and Gigabit Ethernet connectivity.
• Approximate Physical Dimensions (W × H × D):
  • Width: approximately 19.8 mm board thickness
  • Height: approximately 233.4 mm
  • Depth: approximately 160 mm
  • Front panel height: approximately 261.8 mm
  • Form Factor: 6U VME64 single-slot board
• Estimated Shipping Weight: Approximately 1.2–1.8 kg including ESD packaging and protective transport materials.
• What’s in the Box:
  • Motorola MVME5500-0163 processor board
  • IEEE front panel handle assembly
  • VMEbus P1/P2 connector interface
  • Installed MPC7455 PowerPC processor
  • 512 MB ECC SDRAM
  • Flash storage components
  • Anti-static (ESD) shielding bag
  • Protective foam packaging
  • Documentation when supplied with controlled inventory

Product Introduction

The MVME5500-0163 mounts directly into a 6U VME64 chassis, acting as a central processing platform within an embedded control architecture. The board communicates through the VME backplane while providing local computing resources, Gigabit Ethernet connectivity, and PMC expansion capability. Its design supports migration from earlier MVME platforms while maintaining compatibility with established VME installations (which is critical for plants operating validated legacy control systems).

This controller requires careful asset matching before replacement. Verify firmware image, VME address configuration, PMC modules, memory configuration, and operating system compatibility. Inspect the VME connector fingers, ejector handles, processor heatsink, and front-panel interfaces before installation. A visually clean board can still contain outdated boot firmware or incompatible application settings.

Core Technical Specifications

Global Compliance & Industry Certifications

Expected compliance considerations for this class of Motorola industrial computing hardware include:

• CE Mark for applicable EMC requirements when installed inside a compliant equipment enclosure.
• UL/cUL Listed or Recognized status depending on the complete system assembly.
• ATEX/IECEx consideration only when integrated into a certified hazardous-area system with approved enclosure and protection methods.
• Marine approvals such as DNV GL where installed within approved vessel or offshore control equipment.

The is a board-level computing module. It does not provide hazardous-area protection by itself. The complete rack, enclosure, wiring, grounding system, and application approval determine final compliance.

Verify specific lot certifications with OEM.

Long-Term Storage & Asset Preservation Guide

• the inside its original anti-static (ESD) shielding bag. Protect the VME connector contacts and PMC connectors from oxidation.
• Maintain warehouse humidity below 60% RH to protect PCB surfaces, connector plating, and solder joints from long-term environmental damage.
• Inspect stored units every 12–24 months. Record firmware versions, inspect the heatsink area, check mechanical ejector condition, and verify storage packaging integrity (especially after international transport cycles).

Check the date code. Legacy VME assets require accurate records.

Physical Installation Prerequisites

• Install only into a compatible 6U VME64 chassis supporting required backplane signals.
• Verify VME slot assignment, address mapping, and system controller settings before energizing.
• Maintain forced-air cooling through the rack. Leave approximately 50 mm above and below the rack assembly where cabinet design permits.
• Confirm VME power availability:
  • +5 VDC
  • +12 VDC
  • -12 VDC
• Ensure chassis grounding and protective earth bonding are completed.
• Use ESD protection during handling.
• Verify firmware image, boot parameters, PMC hardware, and application software compatibility before commissioning.

Buyer’s FAQ (Logistics & Compliance Focus)

Q: What HS Tariff Code is commonly reviewed for rola ?
A: VME single-board computers are commonly evaluated under HS 8471 or related electronic processing equipment classifications. Final classification depends on the importing country, declared function, and customs authority interpretation.

Q: Does Country of Origin (COO) documentation ma the ?
A: Yes. COO records support customs clearance, supplier qualification, and lifecycle traceability for industrial spare assets. Maintain OEM labels, serial numbers, purchase records, and receiving inspection documentation.

Q: Should shipping insurance be purch the ?
A: Yes. This board contains specialized PowerPC processing hardware, ECC memory, Flash components, and VME interface circuitry. Use ESD packaging, shock protection, moisture barriers, and declared-value freight coverage.

Q: Does rola include the latest firmware pre-loaded?
A: Not necessarily. The board contains Flash storage hardware, but the installed boot firmware and operating environment depend on the specific production unit and previous system configuration. Verify firmware revision, operating system image, and application compatibility before deployment.
