1. REXROTH VT-VPCD-1-15/V0/1-P-1 | Hydraulic Control Spare

2. Unboxing & Physical Snapshot

• Brand & Model: Bosch Rexroth VT-VPCD-1-15/V0/1-P-1
• Product Family: Rexroth VT-VPCD Control Electronics Series
• Product Type: Proportional valve pre-command drive / hydraulic control electronics module. The VT-VPCD series is used for electronic control of proportional hydraulic valves and related closed-loop hydraulic applications.
• Primary Application: Hydraulic servo systems, proportional valve control, machine tools, presses, injection molding equipment, and industrial hydraulic power units.
• Physical Dimensions (Approximate W × H × D):
  • Approximately 35 × 99 × 77 mm (reference configuration).
• Estimated Shipping Weight: Approximately 0.3–0.5 kg including ESD protection and export packaging.
• What’s in the Box:
  • Rexroth VT-VPCD-1-15/V0/1-P-1 control electronics module
  • Terminal/interface connectors (configuration dependent)
  • Product identification label
  • Anti-static (ESD) packaging
  • Protective export carton

3. Product Introduction

Structure B — Architecture Hook

The Rexroth VT-VPCD-1-15/V0/1-P-1 operates as an electronic interface between a hydraulic control command source and a proportional valve actuator. Installed within a hydraulic control cabinet, it converts electrical command signals into controlled valve drive outputs for precise hydraulic movement.

This module belongs to a precision hydraulic control chain, not a standalone PLC accessory. Confirm the valve type, current output range, feedback wiring, and controller compatibility before replacement. Inspect the terminal connections, PCB surface, and enclosure condition carefully (—which is critical in hydraulic systems where unstable valve control can affect machine positioning and pressure regulation).

4. Core Technical Specifications

Parameter	Value
Manufacturer	Bosch Rexroth
Model Number	VT-VPCD-1-15/V0/1-P-1
Product Type	Proportional Valve Control Electronics Module
Series	VT-VPCD
Application	Hydraulic proportional valve control
Supply Voltage	24 VDC nominal
Output Function	Valve drive current control
Control Input	Analog command input (configuration dependent)
Feedback Support	Valve position/pressure feedback dependent
Mounting Method	Cabinet installation / DIN rail style mounting (configuration dependent)
Communication Interface	Analog control interface
Power Consumption	Application dependent
Heat Dissipation	Passive enclosure cooling
Operating Temperature	Approx. 0°C to +50°C (reference configuration)
Protection Class	IP20 cabinet installation
Dimensions	Approx. 35 × 99 × 77 mm
Weight	Approx. 0.3 kg

REXROTH VT-VPCD-1-15/V0/1-P-1

The exact output current rating, feedback configuration, and parameter settings depend on the specific VT-VPCD ordering code and connected hydraulic components. Verify the complete type code before commissioning.

5. ? Global Compliance & Industry Certifications

Expected regulatory considerations for the Rexroth VT-VPCD-1-15/V0/1-P-1 include:

• CE Mark — applicable for compliant industrial machinery installations.
• UL/cUL Recognition — may apply depending on the complete control cabinet certification.
• RoHS Compliance — dependent on production revision and regional requirements.
• ATEX/IECEx — not a standalone hazardous-area certified module; suitability depends on the complete machine certification.
• Marine Approvals (DNV GL) — not standard unless integrated into an approved marine hydraulic system.

For hydraulic machinery, electrical certification alone is not sufficient. Correct integration with valve hardware, pressure systems, and machine safety circuits determines overall equipment compliance.

Verify specific lot certifications with OEM.

6. ? Long-Term Storage & Asset Preservation Guide

Store the VT-VPCD-1-15/V0/1-P-1 inside its original anti-static (ESD) packaging. Protect connector pins and adjustment interfaces from dust and oxidation.

Maintain warehouse humidity below 60% RH. Moisture can degrade PCB coatings and increase corrosion risk on terminal contacts.

Before installation:

• Inspect terminal blocks and connector surfaces for oxidation.
• Verify the model code matches the hydraulic system documentation.
• Check PCB components for discoloration, cracks, or capacitor aging.
• Confirm stored parameters or configuration records are available before replacement.

Do not remove protective packaging until the module is ready for installation.

7. Physical Installation Prerequisites

• Install inside a clean, dry hydraulic control cabinet.
• Confirm 24 VDC supply polarity before energizing.
• Verify grounding connection between cabinet and hydraulic equipment.
• Check valve coil wiring and feedback connections.
• Maintain sufficient airflow around the module for heat dissipation.
• Leave at least 50 mm clearance around cabinet ventilation areas where applicable.
• Secure all terminal connections against vibration.

Avoid installing the module near high-current contactors or sources of electromagnetic interference without proper cabinet separation.

REXROTH VT-VPCD-1-15/V0/1-P-1

8. Buyer’s FAQ (Logistics & Compliance Focus)

Q1. What HS Tariff Code is commonly used for the Rexroth VT-VPCD-1-15/V0/1-P-1?

A: The final Harmonized System classification depends on customs interpretation and the declared function of the module. Hydraulic control electronics may be reviewed under electrical control equipment categories. Confirm the final HS code with your customs broker before shipment.

Q2. Does Country of Origin affect Rexroth VT-VPCD import clearance?

A: Yes. COO documentation supports customs processing, customer asset records, and industrial equipment traceability. Keep the OEM label, commercial invoice, packing list, and inspection records together.

Q3. Is shipping insurance recommended for this control module?

A: Recommended. The module contains sensitive electronic circuits and precision output stages. Shock, moisture, and electrostatic discharge during transport may cause hidden failures.

Q4. Does the VT-VPCD-1-15/V0/1-P-1 include the latest firmware pre-loaded?

A: Firmware availability depends on the exact hardware revision. Some VT-VPCD modules include internal parameter storage, but hydraulic system settings and calibration data must match the connected valve and controller configuration before operation.
