Description
- Schneider AM0MBP001V000 | Original Lexium PLC Interface
Unboxing & Physical Snapshot
- Model & Brand: Schneider Electric AM0MBP001V000 Modbus Plus Communication Card for the Lexium servo drive family. It provides a Modbus Plus fieldbus interface for PLC-to-drive communication.
- Physical Dimensions (Approximate W × H × D): Approximately 120 × 80 × 25 mm (4.7 × 3.1 × 1.0 in.), based on the option card form factor.
- Estimated Shipping Weight: Approximately 0.20–0.35 kg (0.44–0.77 lb) including ESD packaging.
- What’s in the Box:
- Schneider AM0MBP001V000 communication card
- Protective connector cover (when supplied)
- Anti-static (ESD) shielding bag
- Mounting hardware (configuration dependent)
- Product identification label
- Documentation when included by the supplier
Product Introduction
Within a Lexium servo system, the AM0MBP001V000 installs directly into the drive’s option slot to provide Modbus Plus network connectivity. Proper seating of the card-edge connector is essential. Inspect the gold-plated contacts, retaining screws, and communication connector before installation because poor mechanical engagement can produce intermittent network faults (particularly inside high-vibration machinery cabinets).
This communication option is intended for deterministic industrial data exchange between Schneider PLCs and compatible servo drives over a Modbus Plus network operating at selectable data rates. The module does not function as a standalone controller; instead, it extends the communication capability of the host drive. Verify firmware compatibility between the drive and the communication card before commissioning to avoid network initialization errors.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Schneider Electric |
| Model Number | AM0MBP001V000 |
| Product Type | Communication Option Card |
| Product Family | Lexium Servo Drives |
| Communication Protocol | Modbus Plus |
| Network Speed | 500 kbps or 1 Mbps |
| Host Device | Lexium servo drive |
| Connector Type | Sub-D communication connector |
| Installation | Internal drive option slot |
| Power Source | Supplied by host drive |
| Typical Power Consumption | Less than 3 W |
| Heat Dissipation | Less than 3 W |
| User Memory | None |
| Firmware | Drive-dependent |
| Cooling Method | Passive; host drive convection |
| Operating Temperature | Typically 0°C to +50°C |
| Storage Temperature | Typically -25°C to +70°C |
| Relative Humidity | 5–95% RH, non-condensing |
| Estimated Weight | Approximately 0.20 kg |
Schneider AM0MBP001V000
Values marked as typical are based on the communication card class and available product references where Schneider does not publicly publish a complete specification sheet for this option card.
Global Compliance & Industry Certifications
Typical compliance expectations for this category of Schneider industrial communication hardware include:
- CE Mark
- UL/cUL Recognized (as part of approved drive assemblies)
- RoHS compliant (manufacturing revision dependent)
- IEC 61800 compatibility through the host servo drive platform
- ATEX/IECEx suitability only when installed inside an appropriately certified enclosure
- Marine approvals such as DNV only where specified for the complete automation system
CE compliance is particularly important because communication modules become part of the electromagnetic compatibility (EMC) performance of the complete drive system. Improper installation or shielding can increase susceptibility to industrial electrical noise.
Verify specific lot certifications with OEM.
Long-Term Storage & Asset Preservation Guide
Store the communication card inside its original anti-static (ESD) shielding bag until installation. Avoid unnecessary handling of the edge connector.
Maintain storage humidity below 60% RH. Long-term exposure to moisture can oxidize connector contacts and reduce communication reliability.
Inspect the connector pins, PCB surface, and mounting points before installation. If the card has remained in storage for several years, verify hardware revision compatibility with the target Lexium drive before scheduling downtime (this simple check often prevents unnecessary commissioning delays).
Physical Installation Prerequisites
- Power down and isolate the servo drive before installing the option card.
- Confirm compatibility with the target Lexium drive model.
- Insert the module fully into the designated option slot.
- Tighten retaining screws to the manufacturer’s specified torque.
- Ensure cabinet protective earth grounding is properly connected.
- Route communication cables separately from motor power cables.
- Leave at least 50 mm (2 in.) of clearance around the drive to maintain natural convection cooling.
- Verify network addressing and communication parameters before returning the system to service.
Buyer’s FAQ (Logistics & Compliance Focus)
Q: Which HS Tariff Code is commonly used for the AM0MBP001V000?
A: Communication option cards for industrial automation equipment are commonly classified under HS 8517 (communication apparatus) or HS 8538 (parts for electrical control equipment), depending on local customs interpretation. Confirm the final classification with the destination customs authority.
Q: Does the Country of Origin (COO) matter?
A: Yes. COO affects import duties, free-trade eligibility, warranty administration, and equipment traceability. The COO shown on the commercial invoice should match the product identification label.
Q: Is cargo insurance recommended?
A: Yes. Although compact, communication cards contain fine-pitch electronic components and connector assemblies that can be damaged by electrostatic discharge or mechanical impact during international transportation.
Q: Does the include the latest firmware?
A: Not necessarily. Firmware compatibility depends on both the communication card revision and the host Lexium drive firmware. Verify compatibility before installation rather than assuming a replacement card contains the latest supported revision.
