Description
- ICS Triplex T8191 | Industrial Control Cabinet Hardware
Unboxing & Physical Snapshot
- Model & Brand: ICS Triplex T8191
- Product Type: Trusted™ Single Slot Width Shield / Blank Panel for ICS Triplex Trusted TMR chassis systems. The T8191 is a passive mechanical accessory installed in unused chassis positions to maintain rack protection, airflow control, and shielding continuity.
- Approximate Physical Dimensions (W × H × D):
- Approximately 30 × 130 × 25 mm
- Designed to match a single Trusted chassis slot width.
- Estimated Shipping Weight:
- Unit weight: approximately 0.2 kg
- Typical packaged shipping weight: 0.4–0.6 kg
- What’s in the Box:
- ICS Triplex T8191 single-slot shield
- Front retaining/latching features
- Identification marking
- Anti-static protective packaging
- Installation documentation when supplied
Product Introduction
The ICS Triplex T8191 is installed directly into unused positions within the Trusted TMR chassis to preserve the physical architecture of the safety controller rack. It closes empty module openings, maintains the intended airflow path, and helps maintain electromagnetic shielding continuity across the chassis assembly (—which is important in electrically noisy industrial environments).
This is a passive cabinet protection component, not an I/O or communication module. There is no processor, firmware, or signal-processing circuitry inside. Inspect the molded housing, retaining clips, and contact area before installation. A missing or damaged slot shield can affect cabinet housekeeping practices and expose internal rack areas to dust or accidental contact.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | ICS Triplex |
| Model | T8191 |
| Product Family | Trusted™ TMR Safety System |
| Module Type | Single Slot Width Shield / Blank Panel |
| Function | Empty chassis slot protection |
| Electrical Function | None |
| Processor | None |
| Firmware Memory | None |
| Power Consumption | 0 W |
| Heat Dissipation | No active heat generation |
| Mounting Method | Trusted chassis slot insertion |
| Slot Coverage | 1 chassis slot |
| Material | Metal shielding/mechanical enclosure construction |
| Shielding Function | Maintains chassis electromagnetic barrier |
| Cooling Function | Maintains internal airflow path |
| Operating Temperature | Approximately 0°C to +60°C |
| Storage Temperature | Approximately -40°C to +85°C |
| Humidity | 5–95% RH non-condensing |
ICS Triplex T8191
? Global Compliance & Industry Certifications
Expected regulatory considerations for the ICS Triplex include:
- CE Mark: Applicable as part of the complete Trusted system installation where EMC compliance is evaluated.
- UL/cUL Listed: May apply depending on the certified control cabinet assembly.
- IEC 61508 Functional Safety: The does not execute safety logic, but it supports the physical configuration of safety-related Trusted systems.
- ATEX / IECEx: The is not an independent hazardous-area electrical device. Hazardous-area suitability depends on the complete certified system design.
- Marine Approvals (DNV GL): Applicable only when installed as part of an approved marine automation system.
A blanking shield may appear insignificant during maintenance planning, but missing chassis fillers can become an inspection issue because rack configuration no longer matches documented hardware layouts.
Verify specific lot certifications with OEM.
? Long-Term Storage & Asset Preservation Guide
Keep the inside its original protective packaging during storage. Although it contains no electronics, the metal shielding surfaces and retaining features must remain free from corrosion and deformation.
Store in an environment below 60% RH. Moisture exposure can affect surface finish and may reduce mechanical fit quality after extended storage periods.
Inspect before installation. Check the latch mechanism, slot guide surfaces, shielding edges, and identification markings. Do not force a deformed shield into the chassis opening.
Physical Installation Prerequisites
- Install the only in compatible ICS Triplex Trusted chassis assemblies.
- Confirm that the selected rack position is intentionally unused.
- Align the shield with chassis guide rails before insertion.
- Ensure retaining clips engage fully.
- Maintain cabinet airflow paths by filling unused rack openings.
- Leave approximately 50 mm clearance around major ventilation paths where required by enclosure design.
- Verify cabinet grounding and shielding practices remain unchanged.
- Do not install the shield in place of an active processor, I/O, or communication module.
Buyer’s FAQ (Logistics & Compliance Focus)
Q: What HS Tariff Code is commonly used for the ICS Triplex ?
A: The is a passive industrial control chassis accessory. Customs classification is commonly reviewed under industrial control component categories such as HS 8538, but the final tariff code depends on the importing country’s interpretation and declared function.
Q: Does Country of Origin (COO) affect acceptance of the ?
A: Yes. COO information supports customs clearance, import documentation, and spare-part traceability. Match the COO listed on shipping documents with available product records.
Q: Should shipping insurance be purchased for this part?
A: Recommended for international shipments. The main risks are mechanical damage, bent shielding edges, or broken retaining features rather than electronic failure.
Q: Does the ICS Triplex include firmware pre-loaded?
A: No. The is a passive slot shield and contains no processor, memory, firmware, or configuration data.
