Description
- ICS Triplex T8193 | Authentic Trusted System Accessory
Unboxing & Physical Snapshot
- Model & Brand: ICS Triplex T8193
- Product Type: Trusted™ three-slot wide shield / blanking module designed for ICS Triplex Trusted T8100 series chassis. The module fills unused controller or expander chassis positions to maintain correct airflow, mechanical protection, and rack integrity.
- Approximate Physical Dimensions (W × H × D):
- Approximately 130 × 266 × 25 mm (varies slightly by shield assembly revision)
- Three-slot-wide Trusted chassis module format.
- Estimated Shipping Weight: Approximately 0.6-1.0 kg including protective packaging and ESD handling materials.
- What’s in the Box:
- ICS Triplex T8193 Trusted Shield Module
- Front panel assembly
- Retaining hardware / ejector mechanism
- Identification label
- Anti-static (ESD) shielding bag
- Protective foam packaging
- Documentation when supplied
Product Introduction
The ICS Triplex T8193 installs directly into unused three-slot positions within the Trusted T8100 controller or expander chassis. Its physical function is simple but important: close open rack positions, guide cabinet airflow, and prevent contamination from entering the control enclosure (which is critical for maintaining the thermal design of safety-rated TMR systems).
This is a passive mechanical protection component rather than an active processing or I/O module. Do not treat it as a spare controller card. The shield maintains the chassis configuration required by the Trusted platform, preserving airflow paths and preventing incorrect installation of unused rack areas. Verify chassis slot width and rack location before installation.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | ICS Triplex |
| Model | T8193 |
| Product Family | Trusted™ TMR System |
| Module Type | Three-slot wide shield / blanking module |
| Application | T8100 controller and expander chassis unused slot protection |
| Electrical Function | Passive mechanical module |
| Processor | None |
| Memory | None |
| Power Consumption | 0 W |
| Heat Dissipation | No active heat generation |
| Chassis Width | Three Trusted module slots |
| Form Factor | Trusted 3U Eurocard style module |
| Installation Method | Chassis slot insertion with ejector levers |
| Cooling Function | Maintains designed cabinet airflow path |
| Environmental Protection | Prevents dust and debris entry into unused rack areas |
| Operating Environment | Industrial control cabinet environment |
| Compatibility | ICS Triplex Trusted T8100 series chassis |
ICS Triplex T8193
? Global Compliance & Industry Certifications
Expected regulatory considerations for the ICS Triplex T8193 include:
- CE Mark: Applicable when installed as part of a complete compliant Trusted control system.
- IEC 61508 Functional Safety: The shield supports the mechanical integrity of Trusted TMR safety system installations but is not itself a safety logic device.
- UL/cUL Listed: May apply to the complete installed Trusted system assembly depending on certification scope.
- ATEX / IECEx: Not a standalone hazardous-area certified device. Hazardous-area suitability depends on the complete certified safety system and enclosure design.
- Marine Approvals (DNV GL): Applicable only when incorporated into an approved marine automation system.
For compliance records, maintain the module part number, chassis location, system documentation reference, and installation history. Incorrect blanking hardware can affect airflow design and cabinet validation.
Verify specific lot certifications with OEM.
? Long-Term Storage & Asset Preservation Guide
Keep the inside an anti-static shielding bag during warehouse storage. Although it contains no active electronics, the metalwork, connector surfaces, and mechanical retaining features require protection from corrosion.
Maintain storage humidity below 60% RH. Moisture exposure can affect plated contacts, ejector mechanisms, and mounting hardware over extended periods.
Inspect stored shields every 12-24 months. Check the front panel condition, retaining clips, connector area, and identification markings. Replace damaged hardware before installation because missing or damaged rack fillers can disturb cabinet airflow.
Physical Installation Prerequisites
- Install the only in compatible ICS Triplex Trusted T8100 series chassis.
- Confirm the required three-slot opening before installation.
- Ensure ejector levers engage correctly and lock the module into position.
- Verify the chassis airflow path remains unobstructed.
- Maintain cabinet ventilation clearances recommended by the system design.
- Leave adequate space around cabinet cooling paths to prevent heat buildup.
- Confirm protective earth bonding of the cabinet structure.
- Do not install the shield in positions reserved for active Trusted modules.
- Verify rack layout drawings before final assembly.
ICS Triplex T8193
Buyer’s FAQ (Logistics & Compliance Focus)
Q: What HS Tariff Code is commonly used for an ICS Triplex shipment?
A: As a passive chassis accessory, the may be classified differently from active electronic modules. Customs reviews often consider industrial control equipment parts under headings such as HS 8538, but final classification depends on declared function and importing-country rules.
Q: Does Country of Origin (COO) documentation matter for this shield module?
A: Yes. COO records support customs processing, asset traceability, and maintenance documentation. Verify the country marking on the physical label and shipping documents for each unit.
Q: Should the ship with insurance coverage?
A: Recommended. While the module contains no active electronics, damage to the front panel, retaining clips, or mounting structure can prevent proper rack installation and affect cabinet configuration.
Q: Does the ICS Triplex include firmware pre-loaded?
A: No. The is a passive mechanical shield module and does not contain firmware, processor hardware, or memory components.
