Description
- ICS Triplex T9191 | Original Control Cabinet Hardware
Unboxing & Physical Snapshot
- Model & Brand: ICS Triplex T9191
- Product Type: Trusted™ Tall Blanking Cover for unused I/O positions where no Terminal Assembly (TA) is installed. The component closes open chassis locations and maintains the mechanical integrity of the Trusted rack system.
- Approximate Physical Dimensions (W × H × D):
- Approximately 25 × 85 × 15 mm
- Compact molded cover design for Trusted I/O rack positions.
- Estimated Shipping Weight:
- Component weight: approximately 0.06–0.10 kg
- Packaged shipping weight: approximately 0.2 kg with protective packaging.
- What’s in the Box:
- ICS Triplex T9191 Tall Blanking Cover
- Mounting retention features
- Product identification marking
- Protective packaging
- Documentation when supplied
Product Introduction
The ICS Triplex T9191 occupies unused I/O positions inside the Trusted control chassis where a terminal assembly is not installed. Its purpose is physical control of the cabinet environment: closing exposed rack openings, maintaining airflow behavior, and preventing accidental contact with unused internal areas (which is important during maintenance activities in safety-related control panels).
This is a passive mechanical component. Do not classify it as an electronic spare. The molded housing, retaining geometry, and slot coverage are designed to preserve the original chassis arrangement. A missing blanking cover can create unnecessary maintenance concerns because open rack positions may affect dust protection and cabinet housekeeping procedures. Verify the exact chassis location before installation.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | ICS Triplex |
| Model | T9191 |
| Product Family | Trusted™ Series |
| Module Type | Tall Blanking Cover |
| Function | Unused I/O slot protection |
| Electrical Function | None |
| Processor | None |
| Memory | None |
| Power Consumption | 0 W |
| Heat Dissipation | No active heat generation |
| Material | Industrial-grade ABS plastic |
| Flammability Rating | UL94 V-0 |
| Color | Gray / industrial chassis color |
| Protection Rating | IP20 chassis protection maintenance |
| Mounting Method | Chassis slot fitment |
| Operating Temperature | Approximately -20°C to +70°C |
| Storage Temperature | Approximately -40°C to +85°C |
| Humidity Range | 10–95% RH non-condensing |
- ICS Triplex T9191
? Global Compliance & Industry Certifications
Expected regulatory considerations for the ICS Triplex include:
- CE Mark: Applicable as part of the complete Trusted system assembly where EMC compliance is evaluated.
- UL94 V-0 Material Rating: The plastic enclosure material classification indicates flame-retardant characteristics, reducing fire propagation risk inside control cabinets.
- UL/cUL Listed: May apply to the overall installed control system depending on certification scope.
- IEC 61508 Functional Safety: The blanking cover does not perform safety logic but supports the physical integrity of a safety control cabinet installation.
- ATEX / IECEx: Not a hazardous-area certified electrical device. Hazardous-area compliance depends on the complete certified enclosure and system design.
- Marine Approvals (DNV GL): Applicable only when used within an approved marine automation system.
For audit documentation, record the part number, chassis location, and installation history. Small mechanical items are often overlooked during safety cabinet inspections.
Verify specific lot certifications with OEM.
? Long-Term Storage & Asset Preservation Guide
Store the in its original protective packaging. The ABS housing is resistant to normal industrial storage conditions, but prolonged UV exposure or chemical contamination can discolor or weaken the material.
Maintain warehouse humidity below 60% RH. While there are no electronic circuits inside, moisture and contaminants can affect the fit between the cover and chassis slot.
Inspect stored covers before installation. Check the retaining edges, molded surfaces, identification marks, and any deformation caused by compression during storage. A damaged blanking cover should be replaced rather than forced into position.
Physical Installation Prerequisites
- Install the only in compatible ICS Triplex Trusted chassis I/O positions where no terminal assembly is fitted.
- Confirm the correct slot opening before installation.
- Press the cover firmly into position until the retaining features engage.
- Verify that adjacent modules remain properly seated.
- Maintain cabinet airflow paths and keep unused openings covered.
- Ensure cabinet grounding remains compliant with the overall system design.
- Leave adequate clearance around rack assemblies for inspection and service access.
- Keep approximately 50 mm clearance around major ventilation paths where required by cabinet design.
- ICS Triplex
Buyer’s FAQ (Logistics & Compliance Focus)
Q: What HS Tariff Code is commonly used for an ICS Triplex shipment?
A: As a passive chassis protection component, classification may differ from active electronic modules. Industrial control equipment parts are often reviewed under categories such as HS 8538, but the final tariff code depends on customs interpretation and importing-country rules.
Q: Does Country of Origin (COO) matter for a blanking cover?
A: Yes. Even passive components require accurate COO documentation for customs clearance, inventory records, and spare-part traceability. Verify the country marking against export documents.
Q: Is shipping insurance necessary for the ?
A: Recommended for consolidated shipments. Although the part has no electronics, damage to the molded retaining features can prevent proper chassis installation.
Q: Does the ICS Triplex contain firmware or require software loading?
A: No. The is a passive blanking cover and contains no processor, memory, or firmware. Installation only requires correct mechanical fitment within the Trusted chassis.
