1. Motorola MVME61006E-0161R | Authentic Embedded Computer

2. Unboxing & Physical Snapshot

• Model & Brand: Motorola MVME61006E-0161R
• Product Type: 6U VMEbus single-board computer from the MVME6100 series, designed for embedded industrial computing, military/aerospace systems, instrumentation, and long-life automation platforms. The board uses a 1.267 GHz MPC7457 PowerPC processor, 512 MB DDR memory, and 128 MB flash memory.
• Approximate Physical Dimensions (W × H × D):
  • Standard 6U VME64/VME64x form factor
  • Approximately 233 × 160 mm board footprint
  • Depth depends on installed PMC modules and rear transition hardware.
• Estimated Shipping Weight: Approximately 0.7-1.2 kg including ESD packaging, protective foam, and transport carton.
• What’s in the Box:
  • Motorola MVME61006E-0161R processor board
  • Scanbe-style front panel handles
  • MPC7457 PowerPC processor assembly
  • 512 MB DDR memory configuration
  • 128 MB flash storage
  • VME connector assembly
  • Anti-static (ESD) shielding bag
  • Conductive foam protection
  • Documentation package when supplied

3. Product Introduction

The Motorola MVME61006E-0161R installs into a 6U VME chassis backplane and functions as the primary embedded computing controller within the rack architecture. The board interfaces with VME peripherals through the backplane while providing local processing, memory management, Ethernet communication, and expansion support (which is critical for industrial systems where software qualification often extends far beyond the hardware lifecycle).

This controller is typically managed as a controlled replacement asset rather than a general-purpose computer board. The installed firmware image, operating system, PMC configuration, and memory population must match the existing application baseline. The “R” revision was designed as a replacement-compatible version within the MVME6100 family, with the same core configuration and Scanbe handle arrangement. Check the board label before installation.

4. Core Technical Specifications

Parameter	Value
Manufacturer	Motorola
Model	MVME61006E-0161R
Product Family	MVME6100 Series
Product Type	VMEbus Single Board Computer
Form Factor	6U VME64/VME64x
Processor	MPC7457 PowerPC
Processor Speed	1.267 GHz
L1 Cache	Integrated processor cache
L2 Cache	Processor integrated cache
DDR Memory	512 MB DDR SDRAM
Flash Memory	128 MB
VME Interface	VME64 compatible
VME Controller	Tundra TSI interface chipset
PMC Expansion	Supported
Ethernet Interface	Gigabit Ethernet
Serial Interfaces	Serial communication ports
PCI Interface	PCI-based expansion architecture
Non-Volatile Storage	Flash memory / NVRAM functions
Front Panel Type	Scanbe handles
Operating System Support	VxWorks and embedded OS environments (application dependent)
Power Supply	VME backplane DC supply
Typical Power Consumption	Approximately 25-35 W class depending on configuration
Heat Dissipation	Primarily from CPU, memory, PCI bridge, and interface circuitry
Cooling Method	Forced-air chassis cooling
Operating Environment	Industrial embedded system environment

Motorola MVME61006E-0161R

5. ? Global Compliance & Industry Certifications

Expected regulatory considerations for the Motorola MVME61006E-0161R include:

• CE Mark: May apply when the board is installed inside a compliant enclosure and evaluated as part of the finished equipment.
• UL/cUL Recognition: Normally reviewed at the complete VME chassis or equipment level rather than the standalone processor board.
• RoHS Compliance: Verify by manufacturing revision because MVME6100 production spans different regulatory periods.
• ATEX / IECEx: Not a standalone hazardous-area certified device. Hazardous-location suitability depends on the complete certified control system.
• Marine Approvals (DNV GL): Applicable only when integrated into approved marine automation or instrumentation systems.

For legacy VME computing assets, maintain revision history, firmware records, serial numbers, and installed expansion hardware documentation. Hardware substitution without configuration records can create maintenance audit issues.

Verify specific lot certifications with OEM.

6. ? Long-Term Storage & Asset Preservation Guide

Keep the MVME61006E-0161R inside its original anti-static shielding bag during storage. The VME edge connector fingers, DDR memory devices, and processor package require protection from electrostatic discharge and airborne contamination.

Maintain warehouse humidity below 60% RH. Avoid temperature swings that create condensation because connector oxidation may produce intermittent startup faults after years on the shelf.

Inspect stored boards every 12-24 months. Check the front panel handles, connector plating, PCB surface condition, battery-backed areas, and identification labels. Before installation, perform a controlled power-up test and verify the installed firmware image against the existing application record.

7. Physical Installation Prerequisites

• Install the MVME61006E-0161R only in a compatible 6U VME chassis.
• Confirm the backplane supports VME64 signaling requirements.
• Verify forced-air cooling before energizing the board.
• Maintain unobstructed airflow through the card cage.
• Leave adequate clearance around adjacent modules to prevent heat accumulation.
• Inspect VME connector pins before insertion.
• Confirm chassis grounding and protective earth bonding.
• Verify VME backplane power rails before installation.
• Confirm PMC modules and rear transition hardware compatibility.
• Verify boot firmware, operating system image, and application software before commissioning.

8. Buyer’s FAQ (Logistics & Compliance Focus)

Q: What HS Tariff Code is commonly used for a Motorola MVME61006E-0161R shipment?

A: VME processor boards are commonly reviewed under HS classifications associated with electronic computing assemblies, frequently within HS 8471 or related electronic circuit board categories. Final classification depends on customs interpretation and declared function.

Q: Does Country of Origin (COO) documentation matter for this VME controller?

A: Yes. COO records support customs clearance, asset traceability, warranty records, and maintenance documentation. For refurbished inventory, retain manufacturer identification, refurbishment status, and shipment origin details.

Q: Should this PowerPC VME board ship with insurance coverage?

A: Recommended. The MVME61006E-0161R contains processor silicon, DDR memory, flash devices, and precision backplane connectors. Shock, vibration, or moisture exposure can create failures that appear only during system startup.

Q: Does the MVME61006E-0161R include the latest firmware pre-loaded?

A: The board includes factory firmware storage, but the installed image depends on previous service history and application requirements. Confirm the PPC firmware version, operating system image, and customer-specific software before replacement.
