Schneider TSXP572823M | OEM PLC Processor Assembly

Description

1. Schneider TSXP572823M | OEM PLC Processor Assembly

Unboxing & Physical Snapshot

• Brand & Model: Schneider Electric TSXP572823M
• Product Family: Modicon Premium Automation Platform
• Product Type: Double-format PL7 processor module for Modicon Premium PLC systems. It manages the complete PLC station and supports Ethernet TCP/IP and Fipio communication interfaces.
• Primary Application: Industrial automation control, process systems, machine control, infrastructure automation, and legacy PLC installations.
• Physical Dimensions (Approximate W × H × D):
  • Approximately 70 × 270 × 170 mm
  • Double-format Premium rack CPU module.
• Estimated Shipping Weight: Approximately 1.2–1.8 kg including ESD protection and export packaging.
• What’s in the Box:
  • Schneider TSXP572823M processor module
  • Front identification label
  • Communication interfaces (Ethernet/Fipio/serial, configuration dependent)
  • PCMCIA memory slot interface
  • Protective anti-static (ESD) packaging
  • Export transport carton

Product Introduction

Structure B — Architecture Hook

The Schneider TSXP572823M is installed as the central processing unit within a Modicon Premium PLC rack, where it supervises application execution, I/O management, and communication with distributed automation devices. This double-format PL7 processor connects to the Premium backplane architecture and coordinates the complete PLC station.

This processor belongs to a legacy control platform, so replacement requires careful configuration control. Check the hardware revision. Verify the stored application, memory card condition, rack addressing, and communication settings before startup (—which is critical when maintaining production assets that cannot tolerate unplanned PLC downtime).

Core Technical Specifications

Schneider TSXP572823M

The TSXP572823M uses PL7 programming architecture and supports memory expansion through PCMCIA cards. Verify application backup availability before replacing an installed CPU because the processor itself may not contain the complete production program.

? Global Compliance & Industry Certifications

Expected compliance considerations for the Schneider include:

• CE Mark — applicable when installed within a compliant Modicon Premium automation system.
• UL/cUL Recognition — may apply depending on the complete PLC cabinet certification.
• CSA Compliance — applicable for approved industrial installations.
• RoHS Compliance — depends on production revision and regional requirements.
• ATEX/IECEx — not a standalone hazardous-area certified CPU; suitability depends on the complete certified control system.
• Marine Approvals (DNV GL) — only applicable when integrated into approved marine automation systems.

A certified PLC installation helps demonstrate that electrical control equipment meets defined safety requirements. This is especially important in regulated plants where cabinet modifications require documented approval.

Verify specific lot certifications with OEM.

? Long-Term Storage & Asset Preservation Guide

Store the inside its original anti-static (ESD) shielding bag. Protect the backplane connector and front communication ports from dust and oxidation.

Maintain warehouse humidity below 60% RH. Long-term moisture exposure can degrade connector contacts and PCB surfaces.

Before installation:

• Inspect the backplane connector pins for oxidation or contamination.
• Check the PCMCIA slot cover and communication ports.
• Verify battery condition if the stored unit contains backup memory components.
• Confirm the firmware revision and hardware version match the existing PLC configuration.
• Maintain a recorded storage date and inspection history.

For legacy PLC processors, preserving configuration records is as important as preserving the hardware.

Physical Installation Prerequisites

• Install only in an approved Modicon Premium rack position.
• Confirm backplane compatibility before insertion.
• Verify 5 VDC rack power supply capacity.
• Use ESD protection during handling.
• Check Ethernet, Fipio, and serial cable connections before startup.
• Confirm cabinet grounding continuity.
• Maintain cabinet airflow for processor cooling.
• Leave at least 50 mm clearance around ventilation areas where cabinet design permits.

Do not force the processor into the rack. Misalignment may damage the backplane connector pins.

Buyer’s FAQ (Logistics & Compliance Focus)

Q1. What HS Tariff Code is commonly used for Schneider ?

A: The final Harmonized System classification depends on the importing country’s customs interpretation and the declared function of the PLC processor. Industrial automation CPUs are typically reviewed under electrical control equipment categories. Confirm the final HS code with your customs broker.

Q2. Does Country of Origin affect import documentation?

A: Yes. COO information supports customs clearance, customer asset records, and maintenance traceability. Keep the OEM label, commercial invoice, packing list, and receiving inspection report together.

Q3. Should shipping insurance be purchased for this PLC CPU?

A: Recommended. Processor modules contain sensitive electronics, memory components, and precision backplane connectors. Shock, vibration, humidity, or ESD events during transport may cause hidden failures.

Q4. Does the include the latest firmware pre-loaded?

A: The processor contains system firmware, but the user application program is normally managed separately through PL7 software and memory storage media. Verify firmware revision, application backup, and PCMCIA memory compatibility before commissioning.

Note: Schneider Electric has discontinued the commercial lifecycle, with replacement recommendations moving toward Modicon M580 processors for new system designs. Verify lifecycle requirements before purchasing for long-term maintenance inventory
