Foxboro P0972KX | Original I/A Series Fiber Link Assembly

Description

1. Foxboro P0972KX | Original I/A Series Fiber Link Assembly

Unboxing & Physical Snapshot

• Model & Brand: Foxboro P0972KX I/A Series Multimode Fiber Optic Cable. This cable is used for Foxboro I/A Series control network connections requiring optical communication links between compatible network devices.
• Product Type: Multimode Fiber Optic Communication Cable.
• System Family: Foxboro I/A Series Control Network.
• Cable Length: 50 m (165 ft).
• Connector Type: MT-RJ to MT-RJ multimode fiber connector.
• Fiber Type: Multimode fiber optic cable (commonly 62.5/125 μm or system-compatible multimode specification depending on network design).
• Physical Dimensions (Approximate):
  • Cable length: 50 m
  • Outer cable diameter: approximately 3–6 mm (varies by cable construction)
  • Packed coil size: approximately 300 × 300 × 100 mm
• Estimated Shipping Weight: Approximately 0.5–0.8 kg (1.1–1.8 lb) including protective packaging.
• What’s in the Box:
  • Foxboro P0972KX fiber optic cable assembly
  • Factory-installed MT-RJ connectors
  • Protective connector caps
  • Cable identification label
  • Protective packaging

Product Introduction

The Foxboro P0972KX is installed as part of the physical communication layer in an I/A Series control network. Fiber routing discipline matters. Maintain the specified bend radius, protect connector faces, and avoid sharp cabinet entry points because optical damage can remain invisible until the network link fails (which is critical for distributed control systems operating continuously).

This cable provides optical data transmission between Foxboro network components, reducing susceptibility to electromagnetic interference from motors, variable frequency drives, and high-current switching equipment. The P0972KX is identified as a 50 m MT-RJ multimode fiber cable used in I/A Series network architectures. Verify connector type and network equipment compatibility before replacement; similar-looking fiber assemblies may not share the same optical interface.

Core Technical Specifications

Foxboro P0972KX

Global Compliance & Industry Certifications

Expected compliance considerations for the Foxboro include:

• CE Mark — applicable when installed within a compliant Foxboro I/A Series control network system.
• RoHS Compliance — verify according to production revision and documentation.
• UL/cUL Recognition — may apply to associated Foxboro network equipment rather than the passive fiber cable itself.
• ATEX/IECEx — the cable itself is generally not a hazardous-area certified component; suitability depends on the complete installation method.
• Marine approvals (DNV GL) — applicable only when supplied as part of a certified marine automation package.

Fiber optic components are important in industrial safety because optical isolation eliminates electrical conduction paths between separated equipment areas, reducing risks associated with ground potential differences and electrical interference.

Verify specific lot certifications with OEM.

Long-Term Storage & Asset Preservation Guide

Keep the in the original sealed packaging with connector caps installed. Optical connector contamination is one of the most common causes of communication failure after long storage.

Maintain warehouse humidity below 60% RH. Excess moisture can affect connector materials and protective jacket integrity over extended periods.

Before installation:

• Inspect MT-RJ connector faces under suitable lighting.
• Clean connectors using approved fiber cleaning equipment.
• Check cable jacket for crushing, cuts, or permanent bends.
• Confirm cable routing length before installation.
• Maintain the manufacturer’s minimum bend radius.

Do not coil the cable tighter than recommended. Fiber damage may occur internally without visible external marks.

Physical Installation Prerequisites

• Install only with compatible Foxboro I/A Series network equipment.
• Verify MT-RJ connector compatibility before installation.
• Protect connectors during cabinet routing.
• Avoid routing alongside high-voltage motor cables where possible.
• Maintain proper cable separation and mechanical support.
• Secure cable loops without compressing the fiber jacket.
• Avoid sharp bends at cabinet entry points.
• Leave adequate service loop length for future maintenance.
• Verify optical link status after installation.

Buyer’s FAQ (Logistics & Compliance Focus)

Q: What HS Tariff Code is commonly used for the Foxboro ?

A: Fiber optic cable assemblies are commonly classified under HS 8544.70 for optical fiber cables. Final classification depends on connector configuration and destination-country customs interpretation.

Q: Does Country of Origin (COO) affect importing the ?

A: Yes. COO affects customs clearance, duty calculation, and asset traceability. Ensure the commercial invoice, packing list, and cable identification information are consistent.

Q: Is shipping insurance recommended for this fiber cable assembly?

A: Recommended. Fiber cables are lightweight but sensitive to crushing, excessive bending, and connector damage. Transport damage may not be visible until the communication link is tested.

Q: Does the include firmware or configuration data?

A: No. The is a passive fiber optic cable assembly and contains no firmware, memory, or programmable configuration. Network parameters are controlled by the connected Foxboro communication equipment.

Lifecycle Note: The should be stored as a controlled spare asset with connector protection maintained. For legacy I/A Series networks, preserving correct fiber part numbers and connector styles prevents unnecessary troubleshooting during network restoration.
