Description
- Motorola MVME2604-712 | LAM 605-099141-004 Assembly
Unboxing & Physical Snapshot
- Model & Brand: Motorola MVME2604-712, associated with OEM reference 605-099141-004. This assembly is a Motorola MVME2604 VME processor module with 712-series I/O configuration used in industrial computing and semiconductor equipment platforms. ([turn0search1][turn0search3])
- Approximate Physical Dimensions (W × H × D): Approximately 233 × 160 × 25 mm (9.2 × 6.3 × 1.0 in.) for the 6U VME board format.
- Estimated Shipping Weight: Approximately 1.2–1.5 kg (2.6–3.3 lb) including ESD shielding, front panel protection, and transport packaging.
- What’s in the Box:
- Motorola MVME2604-712 VME processor module
- 712-series I/O transition/interface assembly (configuration dependent)
- Front panel hardware
- Anti-static (ESD) shielding bag
- Protective foam packaging
- Installed firmware memory devices when supplied
- Identification label and traceability documentation
Product Introduction
The Motorola MVME2604-712 mounts into a 6U VMEbus chassis, where the board interfaces with the VME backplane through standard rear connectors. Correct backplane compatibility, slot assignment, and airflow direction must be verified before installation. The retaining screws and card guides should hold the module securely without excessive force (which prevents damage to the VME connector contacts).
This controller was built for long-life embedded applications requiring PowerPC processing, VME communication, and dedicated I/O expansion. The MVME2604 family supports different CPU speeds and memory configurations, including versions using 200 MHz, 333 MHz, or 400 MHz processors with memory options from 16 MB to 512 MB. ([turn0search2]) The 712 I/O configuration is frequently encountered in specialized industrial equipment, including semiconductor manufacturing platforms. ([turn0search3]) Inspect the PCB surface, connector pins, memory devices, and I/O interface hardware before returning stored inventory to service.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Motorola |
| Model Number | MVME2604-712 |
| OEM Reference | 605-099141-004 |
| Product Type | 6U VME Single Board Computer with I/O Configuration |
| Processor Family | PowerPC architecture |
| CPU Speed | Configuration dependent; 200/333/400 MHz variants |
| Memory Capacity | 16 MB to 512 MB SDRAM configurations |
| VME Interface | VMEbus compatible |
| I/O Configuration | 712-series I/O interface |
| Expansion Support | PMC/PCI expansion options depending on version |
| Ethernet Interface | Integrated Ethernet capability |
| Serial Communication | Serial interfaces dependent on configuration |
| Non-Volatile Storage | Flash memory / boot firmware support |
| Power Input | VME +5 VDC and auxiliary rails |
| Typical Power Consumption | Approximately 20–35 W class depending on CPU and memory |
| Cooling Method | Forced-air VME chassis cooling |
| Board Format | 6U VME |
| Mounting Method | VME card guides and backplane connectors |
Motorola MVME2604-712
([turn0search1][turn0search2])
Global Compliance & Industry Certifications
Expected regulatory approvals and compliance considerations for the Motorola -712 include:
- CE Mark compliance when installed within a qualified equipment assembly
- UL/cUL recognition where applicable to the complete VME system
- FCC Class A industrial computing emissions considerations
- IEEE 1014 VMEbus compatibility
- RoHS compliance depending on manufacturing date and refurbishment history
- ATEX/IECEx suitability only when installed inside an approved hazardous-area enclosure
- Marine approvals such as DNV GL only for specifically certified applications
EMC certification is normally evaluated at the system level. The chassis enclosure, power supply filtering, grounding arrangement, and external cabling influence final compliance performance.
Verify specific lot certifications with OEM.
Long-Term Storage & Asset Preservation Guide
the inside an original anti-static (ESD) shielding bag. Protect the VME edge connector, I/O interface contacts, and exposed header pins from oxidation and handling damage.
Inspect battery-backed components and memory devices before installation. Extended storage can affect backup batteries and older electronic components, especially when units have remained unused for many years.
Maintain warehouse humidity below 60% RH. Avoid temperature cycling and corrosive storage environments. Before deployment, document the serial number, firmware revision, memory size, I/O configuration, and physical inspection results.
Physical Installation Prerequisites
- Install only in a compatible 6U VMEbus chassis.
- Confirm VME backplane voltage rails and slot configuration.
- Verify the 712-series I/O interface compatibility before installation.
- Use extraction handles and card guides correctly.
- Maintain forced-air cooling through the chassis airflow path.
- Leave approximately 50 mm clearance around ventilation paths where practical.
- Confirm chassis protective earth grounding.
- Inspect rear connectors and front panel hardware before energization.
- Verify installed software and boot firmware compatibility with the target system.
Motorola MVME2604-712
Buyer’s FAQ (Logistics & Compliance Focus)
Q: What HS Tariff Code is commonly used for tola ?
A: VME processor modules are commonly evaluated under HS classifications covering electronic computer assemblies, often within HS 8471 categories. Some industrial control applications may require review under alternative classifications. Final determination should be confirmed by the importing customs broker.
Q: Does Country of Origin affect shipthe ?
A: Yes. COO affects customs documentation, supplier qualification records, and asset traceability. Confirm the origin from the product label, supplier documentation, and commercial invoice before shipment.
Q: Is shipping insurance recommended for this Motorola VME module?
A: Recommended. The board contains processor electronics, memory components, and precision backplane connectors. Use ESD packaging, impact protection, moisture control, and documented receiving inspection.
the include the latest firmware pre-loaded?
A: Firmware depends on the installed Flash/ROM contents and previous application history. The hardware may include boot firmware, but the correct operating image and equipment-specific software configuration must be verified before commissioning.
