Yokogawa CX2420-3-2-2 | DAQSTATION CX2000 Spare

Unboxing & Physical Snapshot

• Model & Brand: Yokogawa Electric DAQSTATION CX2420-3-2-2
• Product family: CX2000 DAQSTATION.
• Configuration: 4 embedded control loops and 20 measurement channels.
• External storage: ATA flash memory card configuration (-3).
• Communication: Ethernet + RS-422A/485 serial interface (-2).
• Displayed language: English (-2).
• Physical dimensions: Verify the exact mechanical drawing before cabinet cutout or replacement work. The CX2420 requires panel-mounting brackets for installation.
• Approximate net weight: 7.5 kg for the CX2420 base configuration.
• Estimated shipping weight: Approximately 9–11 kg packed, depending on carton, protective foam, accessories, and documentation. Weigh the actual shipment before issuing freight documents.
• What’s in the box: CX2420 unit, panel-mounting hardware, ATA flash media where applicable, and documentation/accessories only if included with the specific inventory lot.
• Lifecycle status: The CX2000 family, including CX2420, is a discontinued product family.

Product Introduction

Architecture hook: The CX2420 is a Yokogawa DAQSTATION CX2000 control and measurement station, combining data acquisition with embedded control functions in a panel-mounted instrument. The specifically provides four internal control loops and 20 measurement channels, making the exact suffix configuration important when matching a replacement.

The supplied 3-2-2 configuration is not merely a cosmetic suffix. It identifies the ATA flash storage option, Ethernet plus RS-422A/485 communications, and English display language. Because CX2000 variants can differ in storage media, serial interface, control-loop count, and option boards, a base-model match without the complete suffix can result in an incorrect spare.

Core Technical Specifications

Yokogawa CX2420-3-2-2

Yokogawa’s original documentation confirms the model architecture and suffix coding. The later replacement guide specifically maps configurations into the newer SMARTDAC+ GX20 architecture, confirming that belongs to the legacy platform.

? Global Compliance & Industry Certifications

For this legacy Yokogawa measurement/control station, compliance should be tied to the exact hardware revision and installed option configuration.

• CE Mark: Verify the applicable declaration for the exact configuration.
• UL/cUL: Verify the rating/certification information on the unit and original Yokogawa documentation before making a North American compliance claim.
• ATEX / IECEx: Do not assume hazardous-area certification. The should not be represented as ATEX/IECEx equipment without documentation covering the exact configuration.
• Marine approvals: DNV or equivalent marine certification must be verified separately; do not infer it from the product family.
• EMC: Verify the applicable conformity documentation and installation requirements, including grounding, panel installation, and signal wiring.

The certification record matters because the is an integrated measurement/control station rather than a simple passive recorder. Its communications, control outputs, measurement inputs, and power supply all form part of the installed system’s compliance boundary.

Verify specific lot certifications with OEM.

? Long-Term Storage & Asset Preservation Guide

• Protect the ATA flash media. Preserve the original memory card and its identification with the unit. Do not substitute a random CompactFlash/ATA-compatible card when the stored configuration is operationally significant.
• Control humidity and condensation. Keep the unit in its original protective packaging in a clean, dry warehouse, preferably below 60% RH. Avoid repeated temperature excursions that can produce condensation around the display, connectors, and internal electronics.
• Preserve the front-panel assembly. The display, keys, bezel, and panel-mount hardware should be protected from pressure and impact during storage. Do not stack heavy equipment on top of the .

Before energizing a long-stored , inspect the power connector, communication ports, memory-card interface, display, cooling openings, and internal signs of corrosion. Record the firmware and configuration revision before replacing an operating unit.

Physical Installation Prerequisites

• Install using the specified panel-mounting brackets and the applicable mechanical cutout dimensions.
• Provide adequate rear clearance for power, Ethernet, RS-422A/485, measurement, and control wiring; do not use a generic 50 mm clearance in place of the OEM panel drawing.
• Ensure that the ventilation openings are not obstructed by cabinet structure or cable bundles.
• Establish the required protective grounding connection before energization.
• Keep measurement wiring separated from high-current switching and motor wiring where required by the installation design.
• Confirm the RS-422A/485 termination, polarity, and communication parameters before connecting the serial network.
• Verify the installed ATA flash media and configuration before transferring production operation to the replacement.
• Because this unit contains control outputs as well as measurement circuitry, confirm all output states and interlocks before enabling the replacement in an operating process.

Buyer’s FAQ

Q: What HS Tariff Code should be used for -3-2-2?
A: Classify it according to its actual function as a data acquisition/control station and the tariff rules of the importing country. Do not classify it simply as a generic recorder or computer because the incorporates measurement and control functions.

Q: Does the Country of Origin follow Yokogawa’s corporate location?
A: No. COO must be supported by the actual manufacturing documentation for the specific unit. Record the nameplate origin, supplier declaration, and commercial-invoice information consistently before making any preferential-origin claim.

Q: How should this 7.5 kg unit be packaged for international shipment?
A: Protect the front display and controls from compression, immobilize the chassis inside the carton, and use sufficient cushioning around the panel-mount hardware and connectors. For a discontinued instrument, shipping insurance should be considered based on replacement value and operational criticality rather than weight alone.

Q: Does -3-2-2 include the latest firmware?
A: Do not assume it does. Firmware/configuration should be read and recorded from the actual unit before commissioning. The platform is discontinued, and Yokogawa’s replacement documentation maps configurations to newer GX20 hardware; this makes configuration capture especially important when maintaining a legacy installation.
